R32 Drifter Rod R/T38-Hex 32-R32 Flushing Hole 9.6 mm
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
- WIRE ROPE ACCESSORY,ALUMINUM FERRULE,ALUMINIUM SLEEVES
- ALUMINIUM AND COPPER WIRE ROPE FERRULES,WIRE ROPE ACCESSORIES
- single Aluminium Sleeves,doublf Aluminium Sleeves, mini Aluminium Sleeves
- stainelss steel marine folding anchor
- 100% china new sports car tire 205/55ZR16
- china comfortable car tyre 215/55R17
Product Details
Brand Name: | MIROC | Place of Origin: | China | Model Number: | 4148300560-4148300566 |
Product Description
Description
Drill rod using R32 thread system. With R38 or T38 thread on one shank end. Suited for short hole drilling.
• R28 thread system
• Suitable for small hole range
Color: Based on Customer requirements
Material: Tungsten carbide and high strength alloy steel
Processing: CNC milling and proprietary heat treatment process
Type: R32 Drifter Rod R/T38-Hex 32-R32 Flushing Hole 9.6 mm
Applications
• Underground Mining
• Tunneling
Competitive Advantage
High strength chromium-molybdenum steel with high fatigue strength and excellent wear resistance
specification
<
Part Number | Product Code and Brief Description |
Length (mm) |
Length (ft/inch) |
Diameter (mm) |
Diameter (inch) |
Weight (kg) |
4148300560 |
DRH32-R32R/T38-2400, R32 Drifter Rod, R/T38-Hex 32-R32, Flushing Hole 9.6 mm |
2400 | 7 7/8 | 32 | 1 1/4 | 15.3 |
4148300561 |
DRH32-R32R/T38-3090, R32 Drifter Rod, R/T38-Hex
32-R32, Flushing Hole 9.6 mm |
3090 | 10 1/7 | 32 | 1 1/4 | 19.8 |
4148300562 |
DRH32-R32R/T38-3400, R32 Drifter Rod, R/T38-Hex 32-R32, Flushing Hole 9.6 mm |
3400 | 11 1/6 | 32 | 1 1/4 | 21.7 |
4148300563 |
DRH32-R32R/T38-4000, R32 Drifter Rod, R/T38-Hex 32-R32, Flushing Hole 9.6 mm |
4000 | 13 1/8 | 32 | 1 1/4 | 25.5 |
4148300564 |
DRH32-R32R/T38-4310, R32 Drifter Rod, R/T38-Hex 32-R32, Flushing Hole 9.6 mm |
4310 | 14 1/7 | 32 | 1 1/4 | 27.5 |
4148300565 |
DRH32-R32R/T38-4920, R32 Drifter Rod, R/T38-Hex 32-R32, Flushing Hole 9.6 mm |
4920 | 16 1/7 | 32 | 1 1/4 | 31.3 |
4148300566 |
DRH32-R32R/T38-5530, R32 Drifter Rod, R/T38-Hex 32-R32, Flushing Hole 9.6 mm |
5530 | 18 1/7 | 32 | 1 1/4 | 35.2 |
