Home > Products > Piezo Ceramic Plate > Ultrasonic Welding Piezo Ceramic Plate , Ring Piezoelectric Ceramic
Ultrasonic Welding Piezo Ceramic Plate , Ring Piezoelectric Ceramic
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
Product Details
Brand Name: | CCWY | Place of Origin: | China | Model Number: | CCWY |
Product Description
Certification:CE ROSH TUV
30/10/5 Ring piezo ceramic for ultrasonic welding and cleaning
Quick Detail
30/10/5 Ring Piezoelectric Ceramic:
all kinds of piezoceramics and piezoelectric ceramic.we can produce according to the required size.
the materials have the pzt4,pzt5 ,pzt8 or other required material.
Ultrasonic Welding Piezo Ceramic Plate , Ring Piezoelectric Ceramic
Description
30/10/5 Ring Piezoelectric Ceramic:
◊ High efficiency: high mechanical parameter Q, the transduction efficient between electricity and sound above 95%.
◊ High amplitude: the transducer strength is improved by fixing the high speed vibrator directly on the base of washing groove with bolt. Compare with a magnetic expansion vibrator, its amplitude can be improved above 50%.
◊ Good heat resistance: a large range of working temperature, low resonance impedance and heat productivity.
◊ Good construction: fastened by bolt, easy for assembling, high reliability.
Applications
widely used in all kinds of ultrasonic sensor.ultrasonic transducer.Medical,ultrasonic detectors and so on
Specifications
30/10/5 Ring Piezoelectric Ceramic:
Dimensions (mm) |
Capacity C(pF) |
Weak field dissipation Tgδ (12v) |
Radial frequency Fr (KHz) |
Resonance impedance Zm (∩) |
Coupling modulus Kp (%) |
Φ30xΦ10x5 |
3250±15% |
≤2.0% |
47.5±5% |
≤250 |
≥45 |
Competitive Advantage of Ring Piezoelectric Ceramic:
◊ High efficiency
◊ High amplitude:
◊ Good heat resistance
◊ Good construction:
