Horizontal CNC Hydraulic Wheel Press For Railway Vehicle Repairing
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
- Toilet Paper Cutter/Kitchen Towel Cutting Machine Price with High Performance
- High Capacity 3200mm A3 A4 Paper Writing Paper Recycling Machine, Office Paper Product Machinery for Sale
- Best Price 3200 Model Office Paper Copy Paper Manufacturing Line with Good Reputation
- Henan Toilet Tissue Paper Cutter/Cutting Machine with High Quality
- 1880mm Type Napkin Paper Making Machine Made in China
- Manufacturer Supply1575mm Napkin Paper/Tissue Paper Manufacturing Machine
Product Details
Brand Name: | WKH | Place of Origin: | China | Model Number: | N/A |
Product Description
Certification:ISO9001:2000
Specifications:
Item |
Parameter |
---|---|
Pressure head cylinder max. work pressure |
3150KN |
Pressure head cylinder quantity |
2 |
Pressure head cylinder ram cylinder max. stroke |
700 mm |
Pressure head cylinder diameter |
Ø360 mm |
Gantry max. pass wheel diameter |
1050mm |
Max insert length |
3000 mm |
Movable equipment positioning adjustable distance |
13x200 mm |
Pressure head cylinder plunger rod feeding speed (adjustable) |
3~30mm/s |
Pressure head cylinder plunger rod push mounting speed (adjustable) |
0~3mm/s |
Pressure head cylinder plunger rod return speed (adjustable) |
4~40mm/s |
Two centers max. bearing |
10000kg |
Electricity motive small car quantity |
1set |
Electricity motive small car max. hold up weight |
3500kg |
Electricity motive small car rotation angle |
180degree |
Hydraulic system max. working pressure |
31.5Mpa |
Motor (three phases) voltage |
380V-50HZ |
Boost voltage |
DC 24V |
Installed gross capacity |
50KW |
Pressure sensor accuracy |
≤0.15%FS |
Noise level when running |
75db |
Pressure head measurement inside control precision |
≤0.5 mm |
Pressure head measurement wheel order difference control precision |
≤0.5 mm |
Brake disc distance control precision |
≤0.5 mm |
Brake disc difference control precision |
≤0.5 mm |
Pressure head repeated positioning accuracy |
≤+0.025 mm |
Measurement accuracy |
≤+0.03 mm |
Measurement error precision (Jump) |
±0.02 mm |
Measuring system precision |
0.01 |
Pre-press fitting pressure |
≤50kN |
Oil tank capacity |
1000L |
Machine external dimension(L×W×H) |
6000×2500×2000 mm |
Description:
According to the need of railway speeding up & safety, to improve the quality of manufacture inspection & repair of vehicle running gear, the automatic hydraulic wheel press is developed. The machine consists of main press fit framework, position measuring framework, control system. The machine is used to accomplish the press fitting wheel set of railway vehicles. It can fulfill the press fitting double ends of wheel set at the same time, control the position deviation of the wheel set and the inside distance of two wheel sets to attain the range of the criterion. Meanwhile, it produces the data of wheel set press fit. The machine is widely equipp
