Help Center1KV PVC Insulated Five Cores Fan-Shaped Cables And Wires Low Voltage
Related Products
-
450 / 750V PVC Insulated Cable And Wires Yellow , Blue Color For ConstructionNegotiableMOQ: 1 -
26 / 35KV PVC Insulated Cable Wire With CE , TLC Underground Electrical CableNegotiableMOQ: 1 Piece
-
Custom Copper Conductor PVC Insulated Cable Electrical With CCCNegotiableMOQ: 1 Piece
-
600 / 1000v PVC Insulated And Sheathed Copper Conductor Electrical Cables , WiresNegotiableMOQ: 1 Piece
-
PVC Insulated Underground Burial Aluminum Cable Water-ResistantNegotiableMOQ: 1 Piece
1.insulation:PVC
nductor:copper
3.specification:3 cores *35mm2+2 core *16mm2
4.fan-shaped
PVC-insulated Power Cables
The cable is used for the routine of power supply with the AC rated voltage not exceeding 3.6/6KV. The mechanical, physical and electric characteristics are referenced by GB/T12706-2008(the national standard of china) and IEC60502-1:2004,60502-2:2005(the international standard) The Sheathing Insulated Power Cables with the Rated Voltage 1kv to 35kv and Its Attachment
The sue characteristic and the index of electrical characteristics
1,the permissible installation temperature:≥0°C
2,the long-term permissible operation temperature of conductor:≤70°C
3,Under the condition of short circuit(the max. continuing time should not exceeding 5 seconds) the max. operation temperature:160°C
4, the permissible minimum bending radius:
single core:20D multicore: 20D
5, the AC voltage test of finished cables:
|
KV Rated voltage |
0.6/1 |
1.8/3 |
3.6/6 |
|
KV Test voltage |
3.5 |
6.5 |
12.5 |
|
min Continuing time(min.) |
5 |
5 |
5 |
6,The DCR of conductorcomply with the rules of GB/T3956-2008 The Conductor of Cables.
The type , name and suitable place of the cables
|
type |
name |
Suitable for |
|
|
Copper-conductor |
AL-conductor |
||
|
VV |
VLV |
PVC insulated and sheathed power cable |
Installation in such place as indoor, tunnel, pipeline, cable channel, and flammable and deep-corrosion areas; the mechanical force is unavailable. |
|
VY |
VLY |
PVC-insulated cable sheathed with polythene |
Installation in such place as indoor, tunnel, pipeline, cable channel, and flammable and deep-corrosion areas; the mechanical force is unavailable. |
|
VV22 |
VLV22 |
insulated and sheathed cable with copper tape |
Installation in such place as indoor, cable channel, underground and deep-corrosion areas; the lager tension is unavailable. |
|
VV23 |
VLV23 |
PVC insulated and sheathed cable with steel tape |
Installation in such place as indoor, cable channel, underground and deep-corrosion areas; the lager tension is unavailable. |
|
VV32 |
VLV32 |
PVC insulated and sheathed cable armored with thin steel wire |
Installation in such place as underground, vertical shaft, water and deep-corrosion areas; the lager tension is unavailable. |
|
VV33 |
VLV33 |
PVC--insulted and polythene—sheathed cables armored with thin steel wire |
Installation in such plac |
