Certification:CE ROHS UL
Quick Detail:
15L/m air flowrate
30kpa air pressure
Double diaphragm, duckbill valves
Aluminum body
Continuous working day and night
lifetime more than 20,000hours
size:106x76x74 mm
weight:0.62 kg
Outlet & Inlet Dia: 0.3\" (7.6 mm)
Description:
CINH Mini AC Micro Air Pump QBF-15 series use a unique linear motion design that has the capability of over 20,000 hours of continuous maintenance-free operation. They are compact, cool and highly reliable and inexpensive.
Features:
Compact size Steady air outputs with low noise Very low vibration Low power consumption EconomicalApplications:
intermittend pneumatic compression(medical)
compression therapy
ozone generator
aquarium
recovery system
fragrance diffuser
air bed
Atmospheric Detection
Dosing chemical material
air cloth
medical applications
industrial applications
Specifications:
Air Output: 30SCFH(15Lpm)
Pump Pressure: 4.5PSI(30kpa)
Power Requirement: AC220V,AC120V, AC24V or AC12V, 50Hz or 60Hz
Power Consumption: 10W
Pump Design: Double diaphragm, duckbill valves
Pump Body: Aluminium
Outlet & Inlet Dia: 0.3\"(7.6mm)
Electrical Connections: 1-ft(300mm)Insulated wire pair
Noise Level: 40db unconnected, connected operation will reduce db level
Dimension(LxWxH): 4.2\"x3\"x2.9\"(106x76x74mm)
Net Weight: 0.62kgs
Performance Curve
Competitive Advantage:
long lifetime, low noise, high quality, 15L/M air flowrate and 30kpa pressure, AC Micro Air Pump
