10800Lm 120 Watt Aluminum 117pcs Bridgelux LED Gas Station Light / Canopy Lights Ra 80

Delivery Time:7~10 days
Certification:UL/CUL/CE/ROHS

10800Lm 120 Watt Aluminum 117pcs Bridgelux LED gas station light / canopy lights Ra 80

Quick Detail:

Model Number: J120W or J120W-RF( with reflector) Item Type: LED gas station light LED Light Source: 117pcs Bridgelux Private mold Die Casting Aluminum housing +Tempered Glass+ Meanwell Power supply Power: 120W±5% Input Voltage: AC100-277V Lamp Luminous Efficiency: >90 lm/w Beam Angle: 60°x30°(RF)/120°x120° CRI (Ra>): 75 Color Temperature(CCT): 5700-6500K Working Temperature(℃): -40℃ to 50℃ Working Lifetime(Hour): 40000 Certification: UL/CUL/CE/ROHS Warranty: 5years Size: 400*400*185mm Anti-exploded IP Rating: IP68

Applications:

Widely used in the lighting of gas station, Wall back light and so on.

*actual product may vary from picture show.

LENGTH :  400mm

WIDTH :   400mm

HEIGHT :  185mm

WEIGHT:  11.5 KG

High quality Bridgelux 700Ma 45Mil Efficacy : up to 150lm @ 350Ma (per watt) Rated Life of 100,000+ hrs Operation temp: -30 ºC to +40 ºC No toxic chemicals/Rohs compliant 70%-80%  saving compare to HPS/MH 5 years warranty Highest Ingress Protection rating : IP68

Note	ITEM NO.	DESCRIPTION	TOTAL POWER	Reflector/ wide angle	NOMINAL LUMENS	DRIVE CURRENT	# OF LEDS	SYSTEM  EFFICACY
UL/CE Certify	J120	Replacing 400-500w HPS	120	Optional for both	10,800	350 mA	96	90 LM/W
CE Certify	J100	Replacing 300-400w HPS	100	Optional for both	9,300	300 mA	96	93 LM/W

* Total power consumption may vary due to installation location.

Perfection is the Goal

Material:   Die Cast Aluminum Light Color option:       Cool White

Warm White

Custom color

LENS:  Super Clear Tempered Glass Wide AC input:  90-305 VAC (UL marking: 100-240VAC/277VAC) Power Factor: ~0.98 Total Harmonic Distortion: < 10% Surge protection: IEC/EN 61000-4-5 EMC test standard

 INSTALLATION

Easy installation – plug and play Wall Mount bracket CE: Recognition with CNAS ISO 14001: Recognition with IAF & CNAS ISO 9001: Recognition with IAF & CNAS    UL Certify : ANSI/UL 1598 & ANSI/UL 8750
