Waterproof IP66 Induction Tunnel Lighting with high Luminous Efficiency > 80lm/w
Quick Detail:
Model Number: SD038-80W Item Type: Tunnel induction light Lamp Body Material: Die casting Aluminum housing+ tempered glass Reflector: (two choice) White Nano coating or Vacuum mirror film coating, light transmittance is >90% Naked ballast built in design for better heat dissipation Power: 80W±10% Power Factor: ≥95% Voltage: AC 165V~265V 50HZ Lamp Luminous Efficiency: >80lm/w IP Rating: IP66 Certification: CE, RoHS, Warranty: 5 yearsDescription:
Product: 80W Tunnel Induction light IP66 Model Number: SD038-80W Lamp Body Material: High-Purity Die casting Aluminum housing Tempered glass+ heat resistance silicone seal+hig-!strength aluminum hasp Reflector:White Nano coating or Vaccum mirror film coating choice,light transmittance is >90% Naked ballast built in design for better heat disspersion. separated electrical box:easy assembly/installation Voltage: AC 165V~265V 50Hz Power: 80W±10% Power Factor: ≥95% Lamp Luminous Flux(lm): 6800Lm±10% Lamp Luminous Efficiency(lm/w): >80lm/W Color Temperature: Warm White(3000K), Natural White(4000K), Cool White(5000K-Normal), Cold White(6500K) Working Temperature: -20℃~40℃ Storage Temp. : -40℃~50℃ Lifespan @25℃: 80,000hrs IP Rating: IP66 Certification: CE, RoHS Warranty: 5 years N.W.(g): 7.5KgApplications:
For the railway stations,docks,squares,large billboards,construction sites and three-dimensional lighting of landscape buildings
Specifications:
|
Rated Voltage (VAC/Hz) |
AC165V~AC265V / 50Hz |
|
Wattage (W) |
80W |
|
Color temp. |
2700-6500K |
|
Standard color temp. |
5000K |
|
Lumen(Lm) |
6400Lm |
|
Lifespan (hrs) @25°C |
80,000hrs * |
|
Ambient Temp. (°C) |
-20°C~40°C |
|
Storage Temp. (°C) |
-40°C~50°C |
|
N.W.(g) |
7.5kg |
|
Warranty |
5 years |
|
IP Rating |
IP66 |
Light Distribution Data:
Installtion:
Dimension
Unit(mm)
|
Model |
L |
W |
H |
|
SD038-80W-A |
530 |
335 |
150 |
|
SD038-80W-B |
716 |
335 |
150 |
Packing:
Qty/CTN: 1pc/CTN
Net Weight: 7.5kg
Gross Weight: 8.2Kg
Inner Box: 540x360x142mm
Outside Carton: 600×410×230mm
Competitive Advantage:
1. Patented product, specially designed for lighting source of Tunnel induction light
2. High-Purity Die casting Aluminum housing with high temperature baking is corrosion-resistant and durable, perfect appearance.
3. Tempered glass cover with heat-resistant silicone seal and high-strength aluminum hasp, luminousness can be reached 90%, the IP rating is IP66
4. Reflector: (two choice) White Nano coating(SD038) or Vacuum mirror film coating(SD036), low glare, high light uniform distribution rate and greatly reduces the number of lamps. Reflectivity can be reached 95%
5. Naked ballast built in design for better heat dissipation. And easy assembly/ installation
6. Integrated die-casting of aluminum electrical box with high temperature baking is corrosion-resistant and durable.
7. Applied with our 80W-300W rectangular tube to pr
