YZ Mechanical Wire Tensioner Device For Coil Winding Machine
|
Place of Origin: |
Dong Guan China |
|
Brand Name: |
KIMCHEN |
|
Model: |
YZ Series |
|
Tension test condition: |
Wire speeding 5m/s refer roundness Bobbin |
|
Application: |
Winding machine |
|
Function: |
Tension Control |
|
Product Size: |
135mm*160mm*35mm |
|
Weight: |
0.43KG |
Detailed Product Description:
Mechanical Tensioner(tension device) is one of the vital parts in the coil winding process.It is used to ensure the consistency of the wire tension during the winding process.By using a tensioner,Wire Tension can be adujsted and pre-set to the require value according to the application so as to achieve appropriate winding condition,and to ensure the conformity of each coils technical parameters.
YZ Mechanical Tensioner Specifications:
|
Model |
Applied wire diamiter(mm) |
Tension scope(g) |
|
YZ3S |
φ0．02—φ0．04 |
2．5g—14 |
|
YZ2S |
φ0．04—φ0．08 |
9g—50 |
|
YZS |
φ0．06—φ0．14 |
20g—140 |
|
YZM |
φ0．12—φ0．40 |
70g—600 |
|
YZ2M |
φ0．18—φ0．45 |
120g—1000 |
