1000g - 5000g Coil Winding Mechanical Wire Tensioner TCLL
|
Place of Origin: |
Dong Guan China |
|
Brand Name: |
KIMCHEN |
|
Model: |
TCL Series |
|
Tension test condition: |
Wire speeding 5m/s refer roundness BOBBIN |
|
Application: |
Winding machine |
|
Function: |
Tension Control |
|
Suit: |
Winding of Big Tension |
|
Product Size: |
240mm*170mm*80mm |
|
Weight: |
1.88KG |
Detailed Product Description:
Mechanical Tensioner(tension device) is one of the vital parts in the coil winding process.It is used to ensure the consistency of the wire tension during the winding process.By using a tensioner,Wire Tension can be adujsted and pre-set to the require value according to the application so as to achieve appropriate winding condition,and to ensure the conformity of each coils technical parameters.
TCL Mechanical Tensioner Specifications:
|
Model |
Applied wire diamiter(mm) |
Tension scope(g) |
|
TCL |
φ0．20—φ0．60 |
200g—2000 |
|
TCLL |
φ0．50—φ1.20 |
1000g—5000 |
|
TC3L |
φ0．70—φ2.00 |
2000g—10000 |
