Help CenterIP65 Stainless Steel Keyboard Industrial Metal Desk Top For Coal Mine
Related Products
-
IP65 Dynamic Coal Mine Keyboard With Mechanical/ Optical/ Laser Trackball and Functional KeysNegotiableMOQ: 1 Piece -
IP65 Waterproof Industrial Kiosk Keyboard For Coal Mine With TrackballNegotiableMOQ: 1 Kilogram
-
IP65 Dynamic Coal Mine Keyboard Ruggedized With Functional KeysNegotiableMOQ: 1 Piece
-
IP65 Dynamic Coal Mine Keyboard Industrial With Ruggedized TouchpadNegotiableMOQ: 1 Piece
-
Sealed Desktop Coal Mine Keyboard Vandal Proof With 95 KeysNegotiableMOQ: 1 Piece
Certification:CE,FCC,ROHS,IP65,IP68,ESD
Quick Details:
1. IP65 dynamic vandal proof stainless steel industrial desk top keyboard.
2. With industrial PCB with carbon-on-gold key switch technology with long stroke (2.0mm)
3. CE, FCC, ROHS, IP65, ESD
Descriptions:
1. 95 keys compact format IP65 dynamic vandal proof stainless steel industrial keyboard
2. with industrial PCB with carbon-on-gold key switch technology with long stroke (2.0mm) with extremely good tactile feeling
for fast and accurate data input without any noise
3. with integrated numeric keypad, function keys F1, F2..F10, F11, F12 are on the top panel for easy operation
4. movable stand alone DESK TOP VERSION, or mountable desktop with mounting holes on the bottoms for fixing.
Special Features:
1. Imposing stainless steel design, specially designed keyboards meet the highest demands with regard to design,
functionality, longevity and high protection level.
2. Stainless steel fascia and key-tops guard willful destruction, vandal-proof, against corrosion, weather-proof especially under
extreme climatic conditions, water proof/dirt proof, operation under hostile environments.
3. Waterproof execution according to IP65 protection from top panel.
4. An excellent tactile feel with full-long travel switches and allow users to achieve fast and accurate data input without any
noise. With firm tactile perception for comfortable operation
5. Internet friendly key layout, key-tops are laser-etched in legends and characters for easy readability, long life to prevent
lettering rub-off.
6. Metal keys are protected against twisting and levering which can not be dislodged from front, or defaced removing key
covers.
7. Ease of customizing with multiple languages, to accommodate foreign or custom variants.
8. Complete electronic modules including controller in close consultation with our customers are available.
9. PS/2, USB connection plug-and-play with PC via PC existing OS driver, no needing of install separate driver.
10. The numeric keypad between keyboard and trackball is available with encryption module supporting DES/TDES for bank
usage of CDM/ATM.
Applications:
This Keyboard is mainly targeted for use for:
A: unsupervised or semi -supervised positions of varied access applications,
B: internet terminals and information kiosks at universities,
C: shopping malls, hotels, airports, railway stations and other public areas,
D: ticket vending machines, gas stations, cash machines (ATMs), Internet public phones etc.
Specifications:
MECHANICAL DATA |
|
Key |
95 keys, super quality brushed stainless steel |
Key top style |
Protuberant rectangular keys, with laser engraved and etched legends and raised braille on keys are available |
Key Size |
14.0mm x 14.0mm for normal keys, |
Key travel |
2.0mm |
Switch life |
more than 10 million of operations |
Actuation Force |
0.6N 0.1N for key 14.0mm x 14.0mm (pressure point) |
Mounting Rack |
Aluminum alloy |
Stainless Steel Housing |
Full 1.2mm Super quality brushed stainless steel |
Lettering |
Sunk laser legends & characters in high quality ink |
Actuator/keys materials |
stainless steel |
G.W. |
2.30KGs |
Dimensions |
343.0mm x 148.0mm x 20.0mm (L x W x H) |
ELECTRICAL DATA |
|
Supply Voltage |
+5V DC 5% |
Current Rating |
appr. 20mA |
EMC Standard: |
It is compliance with the council IEC 61000-4-2:2008; |
EMI: |
EN 55022: 2010 |
EMS: |
EN 55024:2010 |
Lifespan |
> 5 years |
Switch Contact Material: |
Carbon-on-Gold key switch technology PCB. |
Interface: |
PS2, USB available. |
OS: |
All windows, Linux, Unix, Mac OSX |
ENVIRONMENTAL ADAPTABILITY |
|
Operating temperature |
-20oC to +60oC |
