C Purlin Cold Roll Forming Machine With High Efficiency 15m/Min
Quick Detail:
C purlin roll forming machine
1, Machine capacity: width:100-500mm, thickness:1-3mm
2, Product speed: 0-15m/min
Description:
Roll forming craftwork:
De-coiler --- Guide, flatting --- Roll forming --- cutting-to-length --- collection table
Unit performance:
1, Machine capacity: width:100-500mm, thickness:1-3mm
2, Product speed: 0-15m/min
3, Total power: about35.5kw
4, Occupy ground area: length 18m xwidth3m
Functions and Features:
Roll forming craftwork:
De-coiler --- Guide, flatting --- Roll forming --- cutting-to-length --- collection table
Unit performance:
1, Machine capacity: width:100-500mm, thickness:1-3mm
2, Product speed: 0-15m/min
3, Total power: about35.5kw
4, Occupy ground area: length 18m xwidth3m
Specifications:
1. De-coiler: de-coiler, Inner expanding , capacity:5T
2. Guide Rack: two pairs of lever rollers and four pairs of standing rollers.
3. Flatting number: 9 sets
4. Roll forming
5. Type: GY160
6. Rack: cast iron torii type, material:HT200
7. Roll forming rack: 12 sets
8. The diameter of the roller axis:φ70mm, roller surface:400mm
9. Material: 40Cr quenching treatment HB280
10.Drive type: every rack has one gear power distribution box.
11.Main power: 30kw frequency conversion, ZQ500 reducer
12.Material:GCr15, Quenching,Hardness:HRC58-62º
13. Assistant roller rack: 4 sets
14.Adjust part: Turkey emendation type (three-dimensional emendation)
15.cutting-to-length:Hydraulic press cutting, power: 5.5kw
Competitive Advantage:
1. our machines are famous for good quality and inexpensive ,
2. we can supply good after sevice .
3. one year guarantee.
4. We can design the machines according to customers’ special requirement .
5. We have professional team for service.
PHOTOS:
