6000BPH High Speed Water Bottle Filling Machine 12 - 50 Heads 380V 12KW

Delivery Time:20-40day after getting the bottle sample
Certification:CE,ISO9001:2001,BV

6000BPH High Speed Water Bottle Filling Machine 12 - 50 Heads 380V 12KW

Quick Detail:

Filling capacity: we can offer 2000bph-20,000bph After service: with professional engineer to customer factory to installment and train Material: sus 304/316 Packing: wooden package Filling level: up to customer, 2mm from the bottle neck, whatever Voltage: 380V 50Hz/ by order Power: 5-18KW PLC/inverse: Japanese Mitsubishi/by order Auto oil adding system Unattached electric control box,convenient and safe With air convey and caps feeding system Filling temperature: 20-40degree Bottle volume: 250ml-2500ml

Description:

Automatic CGF 6000bph non-carbonated drink/pure/mineral water filling machine

The 6000bph mineral water filling machine / machinery / line is a full-automatic multiple-function washing, bottling and capping unit. It is used in washing, bottling and sealing all kinds of non-air drinks such as fruit juice, vinegar,wine,fruit wine, mineral water and drinking water. The line has features of unique design,new style, complete functions,multi-purpose, convenient in operation, beautiful construction, high automaticity. It is the best filling equipment in China.

The machine is mainly used in the water bottling operations. The three functions of bottle rinsing, bottling and capping are composed in one body of the machine. The whole process is automatic. The machine is used in bottling mineral water and drinking water in bottles made of polyester and plastics.The handle of the machine can be freely and conveniently turned to adjust the machine to fill various types of bottles. The bottling operation is faster and more stable because the micro pressure bottling operation of the new type is adopted. Therefore the output and benefit of the machine is higher than the machines of the same specifications.

The advanced Mitsubishi programmed controller (PLC) is adopted to control the machine to run automatically while a transducer is used in the bottle -entering chains to adjust speeds and coordinated with the transducer of the main machine to make the operations of moving bottle forward steadily and reliably . It is convenient to operate with higher automation because every part of the machine is inspected to run with photo electricity. On the bases, the bottling parts of the machine can be changed into bottling methods of lower vacuum. The bottling category of lower vacuum (Z type machine) is applicable in glass bottles, bottling alcohol, soy and such like materials. The aluminum theft proof cap and plastic cap can be adopted. The machine is an ideal equipment for beverage makers.

Characteristics:

1. Using the wind sent access and move wheel in the bottle directly connected technology; canceled screw and conveyor chains, this enable the change the bottle-shaped become easier.

2. Bottles transmission adopt clip bottleneck technology, bottle-shaped transform not need to adjust the equipment level, only change related the curved plate, wheel and nylon parts is enough.

3. The specially designed stainless steel bottle washing machine clip is solid and durable, no touch with the screw location of bottle mouth to avoid secondary pollution.

4. High-speed large gravity flow valve filling valve, filling fast, filling accurate and no liquid lose.

5. Spiraling decline when output bottle, transform bottle shape no need to adjust the height of conveyor chains.

6. Host adopt advanced PLC automatic control technology, the key electrical components from famous company such as Japan\'s Mitsubishi, France Schneider, OMRON.


Technical data

Model	CGF14125	CGF18186	CGF24248	CGF323210
Number of washing,  filling,capping	14-12-5	18-18-6	24-24-8	32-32-10
Capacity;bottle (500ml)/hour	3000-4000	5000-6000	8000-12000	12000-15000
Suitable bottle size  (mm)
