Low Frequency Online UPS 20KVA 30KVA 40KVA 3 Phases Input 1 Phase Output for Instrumentation

Low frequency online UPS 20KVA 3 phases input 1 phase output

Key features:

a).Pure sine wave output, true on-line dual conversion design

b).Adopt 4 layer PCB, and SMD technology

c).High efficiency IGBT (insulated gate bipolar transistor) inverter technology

The 6th generation low-exhaust and big-power IGBT with excellent high speed switch feature, high voltage feature and large current feature. Drives by electric voltage, only need small control power. The 6th generation with lower saturation voltage, the inverter has high efficiency, low temperature, high reliability.

d).Touch screen display, with the simple operation and intuitive data, optional display language and logo

e).Set the work mode on the display directly, UPS mode, ECO mode, EPS mode

f).Intelligent detecting function

This system microprocessor can continually detect power status online, the breaker status and all the working status of the circuit.

g).Excellent load feature

It is completely capable to load from 0-100% while no need to change to bypass, which make sure the output reliable.

h).Cold start

When mains failure, can directly use the battery to start the ups until the battery discharge to low voltage, when mains recover, can self start UPS.

i).Generator compatible

According to the real electric circumstances, UPS can be compatible to the generator, highly improve the generator input efficiency, save the energy.

j).Intelligent communication

With RS232 and RS485 standard collocation, optional SNMP and dry contact

k).Perfect protection

Input/output over/low voltage protection, input surge protection, phase sequence protection, battery over charge/discharge protection, short circuit protection, over-temperature protection and so on, as well as alarm function.

l).Selectable battery inspection module

Can test the single parameter and display on the LCD, battery failure will immediately alarm and inform the administrator.

m).High-powered dynamic feature

Adopt kinds of feedback control such as instantaneous control mode and virtual value, not only reach the high dynamic adjustment, but also reduce the output voltage distortion.

n).Optional input harmonic filter or 12 pulse rectifier

Effectively restrain the input THD, raise UPS input power factor and reduce the input THD current.

Technical specifications:
