Single Phase Rack Mountable Online UPS Double Conversion 3000VA , 110 / 220V AC For Computer

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name

Jendia/OEM

Place of Origin

China

Product Description

Delivery Time:15-20days
Certification:CE,ISO9001
Single Phase Rack mountable Online UPS double conversion 3000VA , 110 / 220V AC For Computer Quick Details

Place of Origin:	China (Mainland)	Brand Name:	OEM	Model Number:	Rack Mount UPS-3KVA
Phase:	Single Phase	Protection:	Overvoltage,Short Circuit	Weight:	12.3/39KG
Output Voltage:	110V/2320V,110/220VAC	Type:	On-line	Application:	Computer,Networking
Online UPS:	Single Phase Rack Mount Online UPS 3KVA	Input Power Factor:	>0.98	Outpt Power Factor:	0.7
Waveform:	Pure Sine Wave

Specifications

1.Single Phase Rack Mount Online UPS 3KVA
2.Advanced battery management
3.Optional 110/220VAC

High Frequency Single Phase Rack Mount Online UPS 3KVA Working For Computer

Application:
Rack mounted server and other networking equipment

Feature:
Rack convertible
High Frequency and double conversion online technology
Fully digitized microprocessor control
Smart RS232 communication with monitoring software
Optional SNMP card slot
Wide input voltage range
Advanced PFC technology
Self-testing when UPS startup
Advanced battery management
Automatic battery charging in UPS off mode
Lighting and surge protection
Short circuit and overload protection
Network/fax/modem surge protection
Optional extension battery pack

Model	1KN/1KS	2KN/2KS	3KN/3KS	6KN/6KS	10KN/10KS
Power Capacity (VA/W)	1KVA/0.7KW	2KVA/1.4KW	3KVA/2.1KW	6KVA/4.2KW	10KVA/7KW
Input
Voltage Range	Load≤60%,55±5V~138±5V; 60%≤Load≤70%,60±5V~138±5V; 70%≤Load≤80%,70±5V~138±5V; Load80%≥80±5V~138±5V.
Frequency Range	46~54Hz(50Hz),or 56~64Hz(60Hz)
Phase	Single phase
Power Factor	>0.98
Output
Voltage Range	110VAC/115V/220VAC±2%
Frequency Range	The same as the utility frequency (Line mode),50Hz±0.2%(Battery mode)
Power Factor	0.7
Waveform	Pure sine wave
THD(Full linear load)	<3%
THD(Full non-linear load)	≤8%(Output :110V),≤10%(Output:115/120Vac)
Current Crest Ratio	3:1 Max
Overload Capacity	Line mode:108%-150%, for 30s ,then transfer to bypass & alarm; >150%, for more than 200ms , transfer to bypass & alarm. Battery mode:108%-150%, for 30s , then turn off & alarm; >150%, for more than 200ms ,then turn off & alarm.
Short-circuit protection	Bypass Mode: the breaker trip off ; AC/Battery mode:Circuit protection,inverter off, fault.
Waveform	Pure sine wave
Transfer time (AC mode & Battery mode)	0ms
Efficiency	≥85%(AC mode );≥83%(Battery mode)
Battery
Type	12V Sealed Lead-Acid Maintenance free Battery
Recharge Time	8hrs to 90% of capacity after full load discharge
LED/LCD Indicators
Status	Load Lever/Battery lever,battery,Utility Power,Inverter,Bypass,ove
