Hammer Crusher
Application fields:
widely used in mining ore crushing, construction materials, cement, aggregate, dry mortar, concrete mixing station.
Materials:
Limestone, coal, salt, gypsum, alum, white rock, brick, tile, coal gangue and so on.Also used for crushing strong fiber structure, flexibility and toughness of chopped wood, paper or broken asbestos cement waste recycled fibro, and so on.Coal, salt, gypsum, alum, white rock, brick, tile, coal gangue and other materials.
Product advantage:
Hammer Crusher with low investment, high yield, the fastest known, renowned in the industry. Sunstone hammer crusher only broke one time instead of the traditional hammer crusher, so that the cost is reduced; The machine adopts the grate design, greatly improve the yield. New type hammer Crusher of Sunstone is at the advanced level in the industry.
Working Principle:
The rotor rotates at a high speed in the crushing cavity by motor.Material is ground by the below, impact, shear, abrasive of the rapidly moving hammer.The lower part of the rotor has a sieve plate, and crushing material less than sieve size fractions discharge through the sieve plate, coarse grain greater than the sieve size resistance continue to be combated and by the hammer,and finally discharge through the sieve plate.
Specification:
|
Model |
Rotor specs (mm) |
Feeding size (mm) |
Feed particle size(mm) |
Capacity |
Power (kw) |
Overall dimensions(mm) |
|
PCZ1308 |
1310×790 |
850×800 |
≤600 |
100-160 |
132 |
2818*2100*2390 |
|
PCZ1510 |
1500×900 |
1000×90 |
≤700 |
160-210 |
132*2 |
3260*2414*2750 |
|
PCZ1512 |
1500×1160 |
1200×900 |
≤750 |
250-320 |
160*2 |
3260*2624*2750 |
|
PCZ1615 |
1650×1452 |
1500×1200 |
≤1000 |
360-420 |
200*2 |
3456*2915*3185 |
|
PCZ1620 |
1660×1900 |
2000×1200 |
≤1200 |
500-800 |
315*2 |
3500*3100*3200 |
Hammer Crusher Equipment Specification:(Standard)
|
Model |
Rotor specs (mm) |
Feeding size(mm) |
Feed particle size(mm) |
Capacity |
Power (kw) |
Overall dimensions(mm) |
|
PC-0706 |
700*570 |
618*510 |
≤400 |
50-70 |
75 |
1950*1340*1480 |
|
PC-0808 |
800*750 |
780*610 |
≤500 |
80-100 |
132 |
2280*1790*1670 |
|
PC-0910 |
900*1000 |
1070*750 |
≤600 |
150-200 |
110*2 |
2600*2200*1940 |
|
PC-1012 |
1000*1180 |
1255*810 |
≤650 |
250-300 |
132*2 |
2800*2310*2210 |
|
PC-1213 |
1200*1280 |
1350*900 |
≤750 |
300-350 |
160*2 |
2970*2580*2510 |
