Certification:CE ROHS ISO
Pitch 5MM PH Indoor Full Color Large Led Display For Airport Advertising , SMD3528
Quick Detail:
1) Stable quality:Opto + Silan chipset;
2) High brightness:1500 ~1800nits;
3) Scan driver:1/16 current;
4) Module size(L*W):160*160mm;
Description:
P5 Indoor Full Color LED Display Screen
5mm pixel pitch,1R1G1B,40000 dots/sqm,P5 Indoor Full Color LED Display Screen creates comfortable brightness and energy saving,display variable video resources,animations,messages to attract attention. We can see P5 Indoor Full Color LED Display Screen in many occasions,like Sports,advertising,traffic,entertainment,stage,events,stations,shopping center,airport,exhibitions, car shows, fashion shows, concerts, ceremonies, etc
Applications Occasions:
Sports,advertising,traffic,entertainment,stage,events,stadium,train station,bus station,shopping center,airport,exhibitions, car shows, fashion shows, concerts, ceremonies, etc
Specifications:
P5mm Indoor Full Color LED Display Screen:
|
Pixel configuration |
SMD3528 1R1G1B 3 in 1 |
|
LEDs configuration |
Red:wave length: 625~630nm;300-400mcd |
|
Pixel pitch(mm) |
5 |
|
Pixel density(dots/sqm) |
40000 |
|
Calibrated brightness(cd/sqm,nit) |
1800 nits(adjustable) |
|
Calibrated brightness proportion ratio |
R:G:B = 3:6:1 |
|
Contrast ratio |
4,500:1 |
|
Brightness adjustment(dimming) |
100 grade auto/manual-adjustment |
|
View angle(degree)(50% brightness) |
V140/H140 |
|
Color capability |
4.4 trillion |
|
Refresh rate(Hz) |
>800 Hz |
|
Frame frequency(Hz) |
>60 Hz |
|
Interface port |
DVI interface(DVI connector) |
|
Input signal |
VGA, Video, AVI, MOV, MPG, DAT, VOB etc. |
|
LED Drive |
Constant-current |
|
Lifetime(hours)(50% brightness) |
100,000 hours |
|
Signal transmission direction |
Horizontal |
|
Operating temperature(Celsius degree) |
-30 ~ 65 |
|
Storage temperature(Celsius degree) |
-35 ~ 70 |
|
Operation humidity(RH) |
0-95% |
|
Operation humidity(RH) |
0-99% |
|
Service |
Front and back service optional |
|
Control mode |
Synchronous & asynchronous available |
|
Communication options |
Wire Ethernet, Fiber Ethernet,RF wireless,GPRS |
|
Power |
120/240 VAC single phase(50-60Hz) |
|
Maximum power consumption(W/sqm) |
800 |
|
Average power consumption(W/sqm) |
