P4 Indoor Full Color LED Display , Sport Die-casting Aluminum Cabinet 1/16 Scan
Quick Detail:
1) Stable quality:Opto + Silan chipset;
2) High brightness:1400 ~1600nits;
3) Scan driver:1/16 current;
4) Cabinet size(L*W):480*480mm;
Description:
P4 Die-casting Indoor Full Color LED Display Screen
4mm pixel pitch,1R1G1B,62500 dots/sqm,P4 Die-casting Indoor Full Color LED Display Screen creates comfortable brightness and energy saving,display variable video resources,animations,messages to attract attention. We can see P4 Die-casting Indoor Full Color LED Display Screen in many occasions,like Sports,advertising,traffic,entertainment,stage,events,stations,shopping center,airport,exhibitions, car shows, fashion shows, concerts, ceremonies, etc
Applications Occasions:
Sports,advertising,traffic,entertainment,stage,events,stadium,train station,bus station,shopping center,airport,exhibitions, car shows, fashion shows, concerts, ceremonies, etc
Specifications:
P4mm Die-casting Indoor Full Color LED Display Screen:
|
Pixel configuration |
SMD2020 1R1G1B 3 in 1 |
|
LEDs configuration |
Red:wave length: 625~630nm;300-400mcd |
|
Pixel pitch(mm) |
4 |
|
Pixel density(dots/sqm) |
62500 |
|
Calibrated brightness(cd/sqm,nit) |
2500 nits(adjustable) |
|
Calibrated brightness proportion ratio |
R:G:B = 3:6:1 |
|
Contrast ratio |
4,500:1 |
|
Brightness adjustment(dimming) |
100 grade auto/manual-adjustment |
|
View angle(degree)(50% brightness) |
V140/H140 |
|
Color capability |
4.4 trillion |
|
Refresh rate(Hz) |
>800 Hz |
|
Frame frequency(Hz) |
>60 Hz |
|
Interface port |
DVI interface(DVI connector) |
|
Input signal |
VGA, Video, AVI, MOV, MPG, DAT, VOB etc. |
|
LED Drive |
Constant-current |
|
Lifetime(hours)(50% brightness) |
100,000 hours |
|
Signal transmission direction |
Horizontal |
|
Operating temperature(Celsius degree) |
-30 ~ 65 |
|
Storage temperature(Celsius degree) |
-35 ~ 70 |
|
Operation humidity(RH) |
0-95% |
|
Operation humidity(RH) |
0-99% |
|
Service |
Front and back service optional |
|
Control mode |
Synchronous & asynchronous available |
|
Communication options |
Wire Ethernet, Fiber Ethernet,RF wireless,GPRS |
|
Power |
120/240 VAC single phase(50-60Hz) |
|
Maximum power consumption(W/sqm) |
900 |
|
Average power consumption(W |
