Digital Electric Steam Generator Stainless Steel 12kw 380V for Home

Delivery Time:1-3 workdays
Certification:CE

boil dry protection stainless steel steam generators KSA-E120 12.0kw/400v/3phase with auto drain function for home and commercial use

Quick Detail:


Type: Wet Steam Sauna control panel: digital and optional Power output: 12.0kw voltage: 380V~400V Main Material: stainless steel tank and shell Color: stainless steel Current: 18.2A phase: 3 Auto protection: over-heat protect, boil dry protect, pressure balancing valve, leakage protect, lack of water protect and the others Auto function: auto water inlet , auto drain, auto flushing, auto power off Shape: Cuboid Size: 475*185*450mm Room volume(cubic meter):11~14 Usage: steam sauna room working time: 1~60 minutes or long time Heating: heat elements Power source: Electric Time Setting: 1-60mins Temperature range to control: 95 F degree~131 F degree Temperature range to show on control panel: 43 F degree ~140 F degree

Heat element material: stainless steel 304, 6pcs 2.0kw

Shell material: stainless steel 304

Water tank material: stainless steel 304

Power: 12.0kw

Room volume use: 11~14 cubic meter

Recommend features: auto drain, auto turn on/ turn off, auto pressure relief, auto cut out when over heat

Digital and optional Sauna Steam Generator stainless steel 12kw 380V for home

Description:

Controls sauna temperature Temperature high limit switch With cleaning and draining function Power:120kW, voltage: 220/380V, phase:1/3 Two controllers: KSA-elegance Operates machine for 1~60 minutes before turning off Automatically shuts down when water level is too low High quality with 2-year warranty Our 16 years experience will help you make the business easily. “Save Worry Save Trouble”!

Applications:

Fit for home use and commercial use

Make you more healthy!

Specifications:

boil dry protection stainless steel steam generators KSA-E120 12.0kw/400v/3phase with auto drain function for home and commercial use  :

Control panel with Digital display Control panel used the advanced inducing technology Controls sauna temperature 35 degree to 55 degrees Controls sauna time 1 minute to 60 minutes or long time Intelligent to heat by segment Intelligent to fill water with steam Intelligent to do a self flushing cycle Light can be connected to controller Intelligent to indicate fault with the code Can pause at working To show CH can working for long Intelligent to save two sets of temperature, can individual set time by memory Automatically shuts down when water level is too low Temperature high limit switch Waterproof grade: IPX5 Auto protection: over-heat protect, boil dry protect, pressure balancing valve, leakage protect, lack of water protect and the others Auto function: auto water inlet , auto drain, auto flushing, auto power off

           We will provide some spare parts to our customer as replacement.

Please see the details for your installment reference:

Model	Power KW	Room volume (m³)	Power requirements           50/60Hz	Current (A)	Power        wire (Copper)          N*mm2	Dimensions  CM	Packing dimensions CM	Gross weight kg
KSA-E120	12.0	11~14	380-415V3N~	18.2	5*4	51*18.5*46	56.5*23*59	17.5~18.5

KSA-E120

Competitive Advantage:

Our quality control is strict. It contains operational test of every steam generator before packing, power test, earthing resistance test, high voltage test,  controller is tested for all functions and 48 hour continual test for circuit board.
