3T Heavy Machine wheel loader ZL30F

Rated load: 3000kg
Total weight:9600kg

Dim.: 6890*2430*3070 mm

Engine: 92kw Diesel Engine

Automatic Transmission

Features:

1.         Equipped with re-optimized diesel engine that has strengthened cold start ability and strong power to greatly improve the working efficiency and performance of the whole machine.

2.         Adopting advanced cooling system that can withstand 40° high temperature and can play its highest performance even in a highly dusty environment.

3.         Adopting full hydraulic steering system and hydraulic valves designed and made by international advanced technology with stable and reliable quality to improve the performance of the hydraulic system.

4.         Adopting high quality ISR hydraulic hoses which strength and reliability are greatly improved.

5.         Adopting countershaft gearbox with power shift transmission, featured by simple structure, high transmission efficiency, long service life, easy maintenance, more gears and high speed, that is suitable for heavy load operating conditions.

6.         Adopting the structural parts designed manufactured by finite element analysis method that has high strength and is fit for heavy load operating conditions.

7.         Adopting tempered glass, the cab has a wide view and furnishes a comfortable driving environment.

8.         Adopting bigger counterweight to enable the wheel loader to have bigger load capacity.

9.         Adopting brand new cooling system design that can meet -20°C ~ +43°C environmental temperature requirements.

Main Technical Parameters:

1.      Rated Load                                                               3000 kg

         2.      Total Weight                                                            9600 kg

         3.      Rated Bucket Capacity                                         1.7-2.5 CBM

         4.      Max. Tractive Force                                                        ≥ 97 KN

         5.      Max. Breakout Force                                            ≥ 127 KN

         6.      Max. Gradeability                                                   30°

         7.      Max. Dumping Height                                          3100 mm

         8.      Max. Dumping Reach                                           1006 mm

         9.      Raising Time                                                            4.8 ± 0.2 s

         10.   Total Cycle Time                                                      9.15 ± 0.5 s

         11.   Overall Dimension (L x W x H)                             6890*2430*3070 mm

         12.   Min. Turning Radius                                              5097 mm

         13.   Engine Model                                                          YUCHAI YC6B125-T20/WEICHAI DEUTZ TD226B (WP6G125E22)

         14.   Engine Type                                                              Vertical, In-line, Water Cooling, 4-stroke Diesel Engine

         15.   No. of Cylinder-Bore/Stroke of Engine              6-108×125 mm

         16.   Engine Rated Power                                              92 kW – 2200 rpm

         17.   Engine Max. Torque                                              500 N.m

         18.   Engine Min. Fuel-consume Ratio                        ≤ 210 g/kW•h

19.   Transmission System                                          YJ315-X Hydraulic Torque Converter

         20.   Gearbox Mode                                                        Countershaft Constant-Mesh Power Shift

         21.   Gear Shift                                                                 4 Forward Shift, 2 Reverse Shift

         22.   Max. Speed                                                              40 km/h

         23.   Drive Axel Main Reducing Mode                        Bevel Gear Grade 1 Reduction

         24.   Drive Axel Hub Reduction Mode                         Planetary Reduction Grade 1

         25.   Wheel Tread                                                            1800 mm

         26.   Wheel Base                                                              2660 mm

         27.   Min. Ground Clearance                                        400 mm

         28.   Hydraulic System Working Pressure                16.5 MPa

         29.   Fuel Tank Capacity                                                  156 L

         30.   Bucket Automatic Leveler                                    Yes

31.   Service Brake                                        Foot Pedal Vacuum Booster, Air Over Hydraulic Caliper Disc Brake on 4 Wheels

         32.   Parking Brake                                                          Hand Lever Flexible Shaft Controlled Disc Brake

         33.   Tyre Type Specification                                         17.5-25-20PR

         34.   Front Tyre Pressure                                                0.4 Mpa

         35.   Rear Tyre Pressure                                                 0.35 Mpa
