Certification:CE
YL-848 CF4HP Four Stations Toe Part Moulding Machine
Quick Detail:
1. Factory direct sales;
2. Advanced technology and reasonable design;
3. Easy operation;
4. High suitability;
5. Save space, labor and time;
6. High efficiency.
CF4HP Four Stations Shoe Moulding Machine For Toe Part / Upper
Description:
YL-848 CF4HP Four Stations Toe Part Moulding Machine with four cold molds works with another shoes equipment of Upper toe shaping machine ALFA67 to improve the efficiency greatly. It is used for molding all kinds of shoes toe parts with high daily capacity and widely welcomed in big sport shoes factories. It only requires one worker to operate with expectable efficiency.
Technical Features:
1. With work table to place upper for convenient operation;
2. Two sides and one central adjustable register nuts for perfect upper positioning;
3. Powerful chiller system;
4. Electronic control card with programmable micro-processor;
5. Automatic start up for machine cycle and rotation;
6. Photo-electric safety switch.
Specifications:
|
Model No.: |
YL-848 CF4HP |
|
Voltage: |
220V |
|
Power: |
4.5KW |
|
Color: |
Red & white, Full white |
|
Measurement: |
1550 × 1700 × 2100 (mm) |
|
Weight: |
1400 kgs |
|
Capacity: |
1600prs/8hrs |
|
Air Pressure: |
6bar |
|
Guarantee: |
1 year |
Competitive Advantage:
1. Italian Technology
2. Italian Quality
3. Original Spare Parts of good condition
4. Made in China
5. Fast Delivery Time
6. Best before, during & After-sales service
7. Competitive Price
Tag: Four Stations Toe-Part Moulding Machine, Hot & Cold Toe Moulding Machine, Toe Upper Forming Machine, Toe-Part Cooling & Heating Forming Machine, Shoe Moulding Machine
