DIN3356 Water Angle Type Globe Valve, High Performance Manual Stainless Steel Cast Iron Globe Valve
Detailed Information :
| Application | ||||||
| 1 | Design According to DIN3320-F32 | |||||
| 2 | Flange End DIN2532/2533 | |||||
| 3 | Nominal Presure PN 10/PN16 | |||||
| Test | ||||||
| Working pressure | PN16 | |||||
| Shell test preesure | 15bars/24bars | |||||
| Seat test preesure | 11bars/17.6bars | |||||
| Main Parts and Materials | ||||||
| Number | Part Name | Material | ||||
| 1 | Body | GG25 | ||||
| 2 | Seat Ring | Stainless Steel | ||||
| Brass | ||||||
| 3 | Disc Ring | Stainless Steel | ||||
| Brass | ||||||
| 4 | Disc | GG25/Carbon Steel | ||||
| 5 | Stem | SS AISI 420 | ||||
| 6 | Bonnet Gasket | Graphite With Soft Steel | ||||
| 7 | Bonnet | GG25 | ||||
| 8 | Packing | Graphite | ||||
| Main Dimensions | ||||||
| Norminal diameter | L | D | D1 | D2 | n-d | H |
| 50 | 230 | 165 | 125 | 102 | 4-Φ18 | 290 |
| 65 | 290 | 185 | 145 | 122 | 4-Φ18 | 320 |
| 80 | 310 | 200 | 160 | 138 | 8-Φ18 | 365 |
| 100 | 350 | 220 | 180 | 158 | 8-Φ18 | 410 |
| 125 | 400 | 250 | 210 | 188 | 8-Φ18 | 460 |
| 150 | 480 | 285 | 240 | 212 | 8-Φ22 | 525 |
| 200 | 600 | 340 | 295 | 268 | 12-Φ22 | 685 |
| 250 | 730 | 405 | 355 | 320 | 12-Φ27 | 830 |
| 300 | 850 | 460 | 410 | 378 | 12-Φ27 | 925 |
| 350 | 800 | 520 | 470 | 435 | 16-Φ27 | 615 |
| 400 | 960 | 580 | 525 | 485 | 16-Φ30 | 630 |
