Home > Industrial Equipment & Components > Compressor > Compressor Unit > 0.75KW, 12KW (380V / 3PH) Heating Tube AWM-20A Industrial Temperature Controller MTC

0.75KW, 12KW (380V / 3PH) Heating Tube AWM-20A Industrial Temperature Controller MTC

Name: 0.75KW, 12KW (380V / 3PH) Heating Tube AWM-20A Industrial Temperature Controller MTC
Brand: AODE
SKU: 148076210
Availability: InStock

0.75KW, 12KW (380V / 3PH) Heating Tube AWM-20A Industrial Temperature Controller MTC thumbnail-1

0.75KW, 12KW (380V / 3PH) Heating Tube AWM-20A Industrial Temperature Controller MTC photo-1

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Brand Name:

AODE

Place of Origin:

China

Model Number:

AWM-20A

Contact Supplier Request Quote Chat Now

Suzhou Honggan Imp&Exp Co.,Ltd

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Product Details
Company Profile
Contact Us

Brand Name AODE

Place of Origin China

Model Number AWM-20A

Delivery Time:20 – 35 work days
Certification:CE & ISO9001:2000

0.75KW, 12KW (380V / 3PH) Heating Tube AWM-20A Industrial Temperature Controller MTC

AWM-20A Mold Temperature Control Units(MTC) are used to preheat a process to the desired operating temperature by engaging the unit\'s electric immersion heater and recirculating the water in the system. Water type MTC circulate high temperature heat transfer fluid through the process application for temperature control. AWM-20A offer the range of temperature control from 15°C to 120 °C.

SAFETY PROTECTIONS:

No-fuse breaker for the overcurrent phenomenon of general power supply. Motor reversion protection and indicator light up. Cooling water lacking protection and indicator light up. Circulating pump overload protection and indicator light up. BY-PASS pressure release loop for hot oil. Phase failure protection. High-voltage explosion-proof device. Anomaly explosion-proof buzzer. Prevent dry combustion device, discharge scale deposit protection. No-voltage exhaust protection system.

SPECIFICATION DETAILS:

No.	Part	Specification	Data
1		model	AWM-20A
2		power supply	3N-380-50HZ
3		Hot medium	water
4		control mode	PC board Self – optimize microprocessor
5		accuracy of temp. control	PID±1℃
6		Max. temperature	120℃
7		Min. temperature	15℃
8		heating power	12KW(adjustable)
9	Pump	model	RGZ-10-120
power	0.75KW
lift	25M
flow	135L/min
10		heating method	Direct heating(Indirect cooling)
11	Pipeline	hot medium inlet/outlet	DN10*4(adjustable)
cooling water inlet/outlet	DN15(adjustable)
drain oil port	DN15(adjustable)
12	Temp. Controller	model	P6100(WEST)
modulating action	Dual PID control of heating & cooling
Temp. interaction stick	K- thermocouple
display status	Respectively display set point & real point
output select	SSR output
13	Frame Size	LWH(mm)	620325645
14
