V Clamp

PRODUCT DESCRIPTION:
V-Clamp consist from profile, or profiled material with one screw and one pad installed on screw.
V-Clamps are usually used together with streamer (prism A8) to create electrical connection between wire
and contact. Streamer is installed or mounted on side of contact and V-clamp pressing a cable to streamer
and it creates a Electrical connection.
Together it create very fast and effective way how to connect cable to various range of low voltage devices
such cabinets, fuse links, fuse disconnector, bus bar systems and many others.

PRODUCT RANGE:
V Clamp                   FA -VC     RM, RE, SM, SE     10-300      mm2     reversible pad
Non reversible V Clamp    FA-VCN     RM, RE, SM, SE     35-300      mm2    not reversible pad
miniV Clamp               FA-mV      RM, RE, SM, SE      6-120      mm2
Steel V clamp             FA-Fe-VC   RM, RE, SM, SE     10-240      mm2
Steel miniV-Clamp         FA-Fe-mV   RM, RE, SM, SE      6-120      mm2
Stainles mini V Clamp     FA-SS-mV   RM, RE, SM, SE      6-120      mm2
V-Cover                   FA-VCover    Cover for FA-VC, FA-VCN, FA-Fe-VC

USED MATERIALS:
V-Clamp - Al alloy, Al or brass bridge nickel tinned.
Steel V-Clamp - Fe alloy w. HDG., bridge brass nickel tinned or Fe with HDG.

PACKING:             FA-VC(N)    FA-mV       FA-Fe-VC     FA-Fe-mV     FA-VCover
Carton dimm :     42x33x25   60x30x20  38x28.5x32   30x22x17   45x29.5x31.5
Contain:                 500pcs       500pcs       500pcs         500pcs        500pcs
Each clamp:          69g               25g            69g                  42g              22g
Netto:                     32kg            32kg          34kg                 20kg            10kg
Brutto:                    33kg             33kg        34.5kg               21kg             11kg

STORAGE AND TRANSPORT:
Product do not have any specific requirements on storage. It is fire-resistant and it is not dangerous.
