Natural White 1740lm 10w Ip65 Outdoor Led Flood Light For Factory, Tunnel Ce / Rohs 3 Years Warranty

Pictures:



Photometric Data:


Description:


1. Bridgelux and Epistar Chip for customer’s choice, 3 years warranty provided

2. 10-240W led flood light available

3.  ISO9001:2008 Quality Management System factory locate in Shenzhen, China

4.The led flood light source adopts the integration of imported single high power LED, with the special design of integrating many chips into one lighting source.

5. The crust in aluminum alloy die casting ensures the efficiency of heat emission, guaranteeing the light a long life span.

6.The high pure imported aluminum from Germany as the reflector has high reflecting efficiency, and it can make sure the luminous flux, controlling the light inside of a useful area. It improves the efficiency of light uniformityuniformity and utilizationutilization, showing the LED advantage of energy saving.uu

7.The integration of 5mm high strength roughened glass and the housing makes the led flood light work perfectly in the high humidity environments.

8. New high efficiency constant current driver. Wide range of input voltage: AC100-240V.

9.No delay start. No waiting. It can reach its normal light as soon as it is turned on. No noise.

10. No electrical wave, conforming to CE.

11.Environment friendly and no air pollution. We exert the design of using cold light source. There is no ill to our eyes and skin. The led flood light do not have lead, hydrargyrum and any other

contamination. It is really environment friendly with ROHS certificate

Specifications:



MAIN SPECIFICATIONS (T=25℃)
NUMBER	ITEM	DESCRIPTION
01	Input Voltage	AC100-240V 47-63Hz
02	LED	1pc
03	Power	20W
04	LED Efficiency	80-90Lm/W
05	Initial Flux	>1800Lm (Cool White)   >1740Lm (Natural White)   >1660Lm (warm white)
06	Power factor	>0.95
07	Color	Warm White /Natural White / Cool White/Red/Green/Blue/Yellow
08	Color Temperature	2700-3300K (Warm White)  4000-5000K (Natural White)  5300-7000K (Cool White)
09	Center Illuminance	1.5M:282 Lux 3.0M:70 Lux 6.0M:13 Lux
10	Beam Angle	120°
11	Life Time	>50,000 Hour
12	Operating Temperature	-25℃ to +55℃
13	Storage Temperature	-40℃ to +65℃
14	Connect Wire	Brown  L Blue   N Yellow/Green  G
15	Certifications
