Help Center1.0'' Chain Transmission 3KW Door Panel Roll Forming Machine
Related Products
-
Roof Panel Roll Forming Machine With 12 - 15m/min Forming SpeedNegotiableMOQ: 1 Piece -
380V, 50HZ, 3 Phase Roof Panel Roll Forming Machine, Panasonic PLC With Touch ScreenNegotiableMOQ: 1 Square Meter
-
5.5kw Hydraulic Cutting Roof Panel Roll Forming Machine With for Outdoor DecorationNegotiableMOQ: 1 Piece
-
Roof and Wall Panel Roll Forming Machine With 18 Groups of Roller StationNegotiableMOQ: 1
-
Wall Panel Roll Forming Machine With Touch Screen PLC Control System for ConstructionNegotiableMOQ: 1 Piece
Certification:CE, UKAS
Main Components:
1. Manual Decoiler
2. Roll forming machine
3. PU foaming & injecting Device
4. Punching machine
5. Automatic tracking cutter
6. Product table
7. PLC control Cabinet
Component Specifications
1. Decoiler: Manual decoiler, capacity 3 tons, coil inner diameter according to user\'s demand.
2. Roll forming machine:
1) Suitable aluminum coil thickness: According to user\'s demand(0.3mm or 0.35mm)
2) Forming shape according to user\'s requirement
3) Roll forming: 36 stands
4) Shaping and calibrating: 20 stands
5) Roll shaft: High grade 45# steel material(precision machining, heat treatment)
6) Roller material: GCr15, quenching and electroplating
7) Main motor power: 5.5KW
8) Way of drive: 1.0\'\' chain transmission
9) Screw and bolt material: SS304
10) Wall panel thickness: 20mm
3. PU foaming & Injecting Device:
1) Low pressure perfusion machine, flux adjustable
2) Use imported high precision nozzle
3) Automatic heating, constant temperature
4. Punching Machine: Punching holes according to user\'s need. Hydraulic station power 3kw, punching moulds material Cr12
5. Automatic Tracking Cutter:
1) Pneumatic compaction and replacement, flying cutting without stopping machine, automatically controlled by PLC system
2) Motor power: 1.5kw
3) Use imported high grade alloy blade, high quality & precision cutting
6. Product table: Simple roll table, 4 meter length
7. Control cabinet:
1) Outline: 700mm× 300mm× 1000mm(L× W× H)
2) Panasonic PLC system, touch screen operation
3) Control the whole line like speed, cutting length, quantity, etc
