Product Details
Brand Name: | Zhongcheng Machine | Place of Origin: | China | Model Number: | FG-75 |
Product Description
Excellent Competitive Price Screw Mineral-washing Machine With ISO9001
1.Introduction of screw mineral washing machine:
Screw mineral-washing machine is mainly applied to washing minerals of large slit content, such as iron, manganese, limestone, tin ore, etc. It carries out mixing, washing, separating, and desliming. With a washing pressure less than 147-196kpa, it is also suitable for washing building materials in construction and power station applications. The gear transmission parts of our screw mineral-washing machine are separated from stones, water and sands, which greatly reduces the error rate of our spiral washing machine.
2.Working Principle of screw mineral washing machine:
Screw mineral-washing machine makes use of buoyancy of water to separate sand from dust and impurity. It achieves purifying, lifting and conveying of the minerals through the stirring of spiral slice. During lifting, the minerals are also stirred so that the coarse sands and fine sands are evenly mixed.
3.Features of screw mineral washing machine:
Screw mineral-washing machine has features like long spiral structure, good sealing system, simple structure, strong processing capability, convenient maintenance, good washing efficiency, etc. It is widely used in mining industry.
4. Main technical parameters screw mineral washing machine:
Type |
Diameter(mm) |
Capacity(t/h) |
Motor power(kw) |
Machine weight(kg) |
FG-60 |
600 |
20 |
3 |
2550 |
FG-75 |
750 |
50 |
5.5 |
3820 |
FG-100 |
1000 |
75 |
7.5 |
4870 |
FG-120 |
1200 |
95 |
11 |
6900 |
FG-150 |
1500 |
130 |
18.5 |
8800 |
Note: for information purposes only, any questions please contact us!
Address: Xigang Industrial Area,Zhengshang Road, Zheng zhou,Henan Province, China
Tel :0371 -67,826,860
