Operating Principles:
Industrial Rotary Dryer is consist of cylindrical shell, back and front riding wheels, feeding device, discharge device, gearing, gear cover and so on. (Besides, the accessory equipment which match with the Dryer is the followings: combustion chamber, feeding device and discharge device, and dust-precipitator, is not the content of the Dryer.)
The heat source of the Dryer is from combustion train. And the Dryer applies co current type of heating. So, after the materials need to be dried put into the cylindrical shell from the feed inlet, they would be pushed forward by spiral shoveling plates. On one hand, because the Dryer shell is placed obliquely, the materials flow to the other side of the shell under the gravity and the power of rotation. On the other hand, the materials are tossed by the shoveling plates repeatedly, and the even heating area of the materials is achieved. The material is dried gradually.
Features:
1. Industrial Rotary Dryer is designed with anti-sticky drum-wall and assembled material-lifting board.
2. This drying equipment is divided into secondary-granulating section, balling section, polishing section and drying section, etc. What worth mentioning is that our dryer features convenient installation and transportation as a result of its flange connection.
3. This large sized drying equipment is primarily composed of vibrating feeder, heating furnace, drying device, and air intake and air outlet device, and more.
The vibrating feeder enables materials to spread uniformly on the mesh belt.
An air-intake fan with large air flow blows away water content of materials, and then the water content will be discharged from the air-outlet.
4. Our dryer has the features of low noise, little pollution and good drying effect.
Technical Parameters:
|
Type (mm) |
Gradient (%) |
Rotate speed(r/min) |
Feeding temperature(℃) |
Power (KW) |
Capacity(t/h) |
Weight (t) |
|
Ф600×6000 |
3-5 |
3-8 |
≤700 |
3 |
0.5-1.5 |
2.9 |
|
Ф800×8000 |
3-5 |
3-8 |
≤700 |
4 |
0.8-2.0 |
3.5 |
|
Ф800×10000 |
3-5 |
3-8 |
≤700 |
4 |
0.8-2.5 |
4.5 |
|
Ф1000×10000 |
3-5 |
3-8 |
≤700 |
5.5 |
1.0-3.5 |
5.6 |
|
Ф1200×10000 |
3-5 |
3-8 |
≤700 |
7.5 |
1.8-5 |
14.5 |
|
Ф1200×12000 |
3-5 |
3-8 |
≤700 |
11 |
2-6 |
14.8 |
|
Ф1500×12000 |
3-5 |
2-6 |
≤800 |
15 |
3.5-9 |
17.8 |
|
Ф1800×12000 |
3-5 |
2-6 |
≤800 |
18 |
5-12 |
25 |
|
Ф2200×12000 |
3-5 |
1.5-6 |
≤800 |
18.5 |
6-15 |
33 |
|
Ф2200×18000 |
3-5 |
1.5-6 |
≤800 |
22 |
10-18 |
53.8 |
|
Ф2200×20000 |
3-5 |
1.5-6 |
≤800 |
30 |
12-20 |
56 |
|
Ф2400×20000 |
3-5 |
1.5-5 |
≤800 |
37 |
18-30 |
60 |
|
Ф3000×20000 |
3-5 |
1.5-5 |
≤800 |
55 |
25-35 |
78 |
|
Ф3000×25000 |
3-5 |
1.5-5 |
≤800 |
75 |
32-40 |
104.9 |
