Steel-welded c type fixed table 315 ton metal pneumatic Power Press Machine stamping press: capacity: 315 ton
die height: 30mm
stroke: 200 mm
depth of throat: 490mm
size of table(L-R*F-B):1350*900m
I. Main Features and Function:
l Steel-welded C-frame, ageing treatment, high rigidity, stable precision;
l Crossed crankshaft, V-type guides of the slide realize high accuracy guidance
l Turn-key and rigid clutch realize flexible movement and reliable performance;
l Press-collapse block device, to ensure safety in press operation;
l Photoelectric protector, feeder and other optional accessories are available for safety & high- efficiency production line
II. Optional configuration:
l Photoelectric protector
l Uncoiler, leveling machine and feeding device
l Air cushion
III. Technical data:
|
item |
JB21-315 |
|
|
Nominal Pressure (KN) |
3150 |
|
|
Nominal Pressure Stroke(mm) |
13.0 |
|
|
Stroke of Slide(mm) |
200 |
|
|
Strokes (S.P.M) |
30 |
|
|
Max. Die Set Height(mm) |
500 |
|
|
Die Set Height Adjustment(mm) |
150 |
|
|
Depth of Throat(mm) |
490 |
|
|
Distance between uprights(mm) |
740 |
|
|
Size of table |
L-R(mm) |
1350 |
|
F-B(mm) |
900 |
|
|
Hole of table |
Diameter* Depth(mm) |
Φ300*200 |
|
Bottom size of Slide |
L-R(mm) |
610 |
|
F-B(mm) |
395 |
|
|
Hole for hand shank |
Diameter(mm) |
Φ80 |
|
Depth(mm) |
80 |
|
|
Motor Power (KW) |
22 |
|
|
Overall Size |
L-R(mm) |
2380 |
|
F-B(mm) |
2485 |
|
|
Height |
3675 |
|
|
Total Weight(kg) |
28000 |
