3. Choose a coordinates reference.
. Type the origin-offset value, if necessary.
4. Click [Close].
. The screen returns to the main menu.
1D3C-EPt-EdBd-001
Page 1-14 1E3C-E-PMB01-A02-00
1.5.2 Board Recognition Data
1. About the board recognition data
1.5 Creating the Production Data
1. Board recognition mode

.
Board-recognition : Points A and B are recognized for each board. The deviation (.x, .y, points AB and .θ) calculated on the basis of the two points is corrected.
.
Board-recognition : Points A, B, and one point on the pattern (Pa) are recognized for each points AB + Pa board.
.
Board-recognition : Points A, B, and two points on the pattern (Pa and Pb) are recognized
points AB + PaPb
.
Board-recognition : Only the point A is recognized for each board. Only the deviation (.x,
point A

2. Board-recognition point
A) Recognition-point coordinates (X, Y) Enter the measurement (X, Y) from the origin of coordinates to the board recognition mark.
E.g.) Case of Right-Rear reference
. Coordinates of board-recognition point A (X1, Y1)
. Coordinates of board-recognition point B (X2, Y2)
. Choose the two marks on board as the recognition points A and B. However, the point A and B should be located as diagonally and away from each other as possible
Explanation
c
Board recognition mark
d

Origin (0, 0)
e
Board flow direction
B) REF Choose the method of recognition. Shape data recognition (REF=125) is normally used for the board recognition.
1E3C-E-PMB01-A02-00
1.5
 Creating the Production Data
2
Editing the board recognition data
. When the board recognition of the software switch is disabled, the data cannot be edited.

1. Click [BoardRecogData] in the main menu.
. The <BoardRecogData> sheet on the <BoardData> window opens.
2
Enter the coordinates of board-recognition point A.
3
Click [SelectREF].
. The <SetREF> window opens.
4. Choose the desired REF, shape, and color. Then enter the size, and click [OK].
. The <SetREF> window closes and the <BoardRecogData> sheet opens.
5. Enter the data of point B by repeating the steps from 2 to 4.

. When selecting points AB + Pa and AB +PaPb, enter the data of the points Pa and Pb in the same way.
193C-EPt-EdBr-004
6. Click [Close].
. The screen returns to the main menu.
1B4C-EPt-EdBr-003
Page 1-16 1E3C-E-PMB01-A02-00
1.5.3 Board Positioning Data
1. About the board positioning data
1.5 Creating the Production Data
1. Y-axis direction clamp operation timing Set the operation timing of the supports and the clamp in fixing the board. By default, “Lower limit” is selected. (Except in the case where the other production-board data is used)
