Base Material |
♦Hot dip galvanized steel sheet(HDG) |
|
Color |
As per the RAL color card or customers’ sample |
|
Coating Mass |
Zinc: 60-275g/m2 AL-ZN: 60-180g/m2 |
|
Thickness |
0.15-1.5mm |
|
Tolerance of Thickness |
-0.03---+0.01mm |
|
Width |
600-1250mm |
|
ID(Inner diameter) |
610mm,508mm |
|
Quality Standard |
EN10142, EN10326, EN10169, JIS3302, ASTMA755M, B/T12754 |
|
Steel Grades |
DX51D, DX52D, DX53D, S220GD, S250GD, SGCC |
|
Type of Paint |
PE, PVDF, HDP, SMP |
|
Coating Type |
2/2 (double coated/double coated) |
|
Top Paint Layer |
20-25µm |
|
Back Paint Layer |
7-12µm |
|
Glossiness |
35-65 ±5° |
|
Weight of Coil |
1-8T |
|
Package Method |
Vertical, Horizontal |
Send Inquiry to This Supplier
