5.5 Kw Automatical Aluminium Corrugated Sheet Roll Forming Machine For Corrugated Sheets

A). Main Specification of Aluminium Corrugated Sheet Roll Forming Machine:

Material thickness: 0.3-0.8mm Material width: depend on customer’s requirement Decoiler Type: manual or automatical type ( depend on customer’s requirement ) Weight Capacity Of Decoiler: 5 Ton Main Motor Power: 5.5 Kw Hydraulic Motor Power: 3 Kw Forming Station: 13-20 ( depend on profile drawing ) Material of Roller: High grade 45# forge steel Axis Diameter: ¢ 76mm Working Speed: 0-15 m/min Type of Cutting: Hydraulic cutting Electrical Control: PLC Frequency Control System with touch screen Machine Weight: about 5 Ton

B).  Main Components:

Decoiler ---------------------------------------------- 1 Unit Feeding guide -------------------------------------- 1 Unit main roll forming machine ----------------------- 1 Unit Hydraulic cutting device -------------------------- 1 Unit Hydraulic Station ----------------------------------- 1 Unit PLC computer control ---------------------------- 1 Unit Output table ------------------------------------------ 1 Unit

C). Work Flowing:

Decoiler --- Fedding Guide --- Roll Forming --- Cut-to-length --- Run out table

Competitive Advantage:

High Quality Reasonable Price Good after Service 1 Year Warranty More Than 10 Years Experience
