Help CenterHydraulic Machine for Carbon Steel Elbow Machine
Related Products
-
Hydraulic Machine for Carbon Steel Elbow MachineUS$ 30000 - 30000MOQ: 1 Set -
Carbon Pipe Elbow Macking Hydraulic MachineUS$ 30000 - 30000MOQ: 1 Set
-
Hydraulic Press for Induction Heating Making ElbowsUS$ 30000 - 30000MOQ: 1 Set
-
Hydraulic Pushing Machine for Carbon Steel Pipe ElbowUS$ 20000 - 20000MOQ: 1 Set
-
Induction Heating Hydraulic Machine for Making Carbon Steel ElbowUS$ 20000 - 20000MOQ: 1 Set
|
Cost (EXW) |
We’d like to assist to handle the export and to deliver the goods to Tianjin Xingang, The buyer pay us for all the charges. |
|
|
|
||
|
The Main Technical Parameters of The elbow Machine 1, Master cylinder: inside diameter: φ250mm diameter of the rod: φ210mm effective strock:12m the max thrust of the 2 cylinders 210T. The other smaller cylinders: φ125mm 2 pieces. 2, Hydraulic pump station a,station configuration: 25scy plunger pump 1 set , 7.5KW Motor 1 set ( to converse frequency adjust the speed of the master pump) PV2R13-17-116 gear pump 1 set ,15KW Motor 1 set ( fast forwad and backward,to guide clamp wheel,fixture motor). The working speed ; 0-20cm/min , the maxmum backward speed:300cm/min 3,The guiding part of the main machine is controled by four wheels, the clamp holding different size run By the hydraulic motor, it open and closed drived by the oil cylinder, the oil cylinder drive the the rocking arm to adjust the bending radius. 4,Medium—frequency power supply:600 KW, 500-1000HZ. The total power of the machinery part: 25KW,380V or 220V,50HZ or 60 HZ |
