H.264 HDD Hard Disk IP54 3G HDTV Digital Mobile DVR Recorder 1/ 2 /4 CH For Taxis

Delivery Time:5--7work days after receive your payments

H.264 HDD Hard Disk IP54 3G HDTV Digital Mobile DVR Recorder 1/ 2 /4 CH For Taxis

Key Features

l  H.264 Compression, Record Resolution Up to D1

l  Dual Stream for Recording and Network transmit

l  Support Hard disk and SD card recording, USB and Network Backup

l  Pluggable hard disk 2.5 \" HDD tray, with mature vibration reduction technology

l  Independent 6 Vehicle status monitor interface, of which one can speed

l  8-32V power input

l  Vent-free enclosure design

Descriptions

VC-MDR700X Mobile DVR adopt highly integrated H.264 ASIC, its image quality is excellent, in addition to using the hard disk as a video storage medium or it can use SD card as an auxiliary video storage medium to improve the stability of record data. Through the built-in USB port the video data can be backed up quickly.

VC-MDR700X In addition to integrated vehicle status monitor, it can support built-in GPS, 2G/3G modules.

The playback software of MDR700X can not only achieve the synchronous and asynchronous multi-channel playback, the video and GPS also enables synchronization of data such as playback, convenient video analysis.

VC-MDR700X can be widely used in buses, taxis, police cars, law enforcement vehicles, and other various types of vehicles.

Specifications
Model	VC-MDR7001	VC-MDR7002	VC-MDR7004
Video Input	1 Ch	2 Ch	4Ch
Video Input Parameter	1.0Vp-p, 75 Ohms,   Aviation plug
Video   Output	1 Ch
Video Output  Parameter	1.0Vp-p, 75 Ohms,   Aviation plug
Video   Compression	H.264
Preview  Resolution	D1 resolution(PAL:704×576, NTSC:704×480)
Dual Stream-Main	30FPS@D1(NTSC) 25FPS@D1(PAL)	60FPS@D1(NTSC) 50FPS@D1(PAL)	120FPS@CIF(NTSC) 100FPS@CIF(PAL)
Dual Stream-Aux	30FPS@CIF(NTSC) 25FPS@CIF(PAL)	60FPS@CIF(NTSC) 50FPS@CIF (PAL)	30FPS@CIF(NTSC) 25FPS@CIF(PAL)
Record Resolution	D1	D1	CIF
Dual Stream Network transmission	Independent  4CIF(HA-01D/02D Only), CIF/QCIF
Playback Frame rate	PAL:1～25 fps , NTSC:1～30 fps
Record band rate	16K～2Madjustable, Customizable (unit:bps)
Audio Input	1Ch	2Ch	4Ch
Audio Input Parameter	2Vp-p Line, 1OK Ohm , Shard the  Aviation plug with video input
Audio Output	1Ch
Audio Output Parameter	3Vp-p, 600ohms, Shard the  Aviation plug with video output
Built-in 2G/3G module	Optional
Built-in GPS Module	Optional
Built-in Wi-Fi Module
