1 / 2 / 4Ch 1 Ethernet Hard Disk 3G H.264 Car Mini Mobile DVR Recorder Black Box Camera

Name: 1 / 2 / 4Ch 1 Ethernet Hard Disk 3G H.264 Car Mini Mobile DVR Recorder Black Box Camera
Brand: Zhengqi
Price: Negotiable

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Supply Ability 0 Piece / Pieces per Month
Payment Terms:T/T L/C D/P D/A
Delivery Detail:7 days

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Brand Name:

Zhengqi

Place of Origin:

China

Product Description

Delivery Time:5--7work days after receive your payments

1 / 2 / 4Ch 1 Ethernet Hard Disk 3G H.264 Car Mini Mobile DVR Recorder Black Box Camera

Descriptions

VC-MDR700X Mobile DVR adopt highly integrated H.264 ASIC, its image quality is excellent, in addition to using the hard disk as a video storage medium or it can use SD card as an auxiliary video storage medium to improve the stability of record data. Through the built-in USB port the video data can be backed up quickly.

VC-MDR700X In addition to integrated vehicle status monitor, it can support built-in GPS, 2G/3G modules.

The playback software of MDR700X can not only achieve the synchronous and asynchronous multi-channel playback, the video and GPS also enables synchronization of data such as playback, convenient video analysis.

VC-MDR700X can be widely used in buses, taxis, police cars, law enforcement vehicles, and other various types of vehicles.

Specifications
Model	VC-MDR7001	VC-MDR7002	VC-MDR7004
Video Input	1 Ch	2 Ch	4Ch
Video Input Parameter	1.0Vp-p, 75 Ohms, Aviation plug
Video Output	1 Ch
Video Output Parameter	1.0Vp-p, 75 Ohms, Aviation plug
Video Compression	H.264
Preview Resolution	D1 resolution(PAL:704×576, NTSC:704×480)
Dual Stream-Main	30FPS@D1(NTSC) 25FPS@D1(PAL)	60FPS@D1(NTSC) 50FPS@D1(PAL)	120FPS@CIF(NTSC) 100FPS@CIF(PAL)
Dual Stream-Aux	30FPS@CIF(NTSC) 25FPS@CIF(PAL)	60FPS@CIF(NTSC) 50FPS@CIF (PAL)	30FPS@CIF(NTSC) 25FPS@CIF(PAL)
Record Resolution	D1	D1	CIF
Dual Stream Network transmission	Independent 4CIF(HA-01D/02D Only), CIF/QCIF
Playback Frame rate	PAL:1～25 fps , NTSC:1～30 fps
Record band rate	16K～2Madjustable, Customizable (unit:bps)
Audio Input	1Ch	2Ch	4Ch
Audio Input Parameter	2Vp-p Line, 1OK Ohm , Shard the Aviation plug with video input
Audio Output	1Ch
Audio Output Parameter	3Vp-p, 600ohms, Shard the Aviation plug with video output
Built-in 2G/3G module	Optional
Built-in GPS Module	Optional
Built-in Wi-Fi Module	Optional
CommunicationPort	1 Ethernet, 1RS232, 1RS485
MemoryPort	1 USB2.0, 2 SD
Vehicle Status Monitor port	6, 1 for speed
