Product Features:
1. Germany Ball Screw Nut, guarantee the working clearance is very small.
2. Broken-point memory ensures the continuity of work when inciddent happens.
3, Gantry movement ensures the undeformation after a long-time work as well as a higher accuracy; Solid gantry, well structure of lathe bed, stable lathe table.
4. Auto-oiling system, confirm the power was uniform in these three axis.
5. Mainly used for breast-plate engraving, & cut 2cm thickness organic glass easily.
6. Cast steel structure, solid without distortion.
7. Water-cooling spindle with low noise and guarantee long time mass processing.
8. Tool sensor system, save your time.
9. Optimized mechanical and electrical design with well-selected brand parts minimizes breakdown rate.
Specification Parameter
| Description | Parameter |
| TZJD-1218 | |
| Working Area (X*Y*Zmm) | 1200mm*1800mm*100mm |
| Max Engraving Speed | 6000mm/min |
| Frame | Cast Square tube welding |
| XYZ travelling positioning accuracy | ±0.03/300mm |
| XYZ repositioning accuracy | ±0.02mm |
| Spindle power(KW) | 1.5 KW/2.2KW/3KW/4.5KW |
| Max. Power Consumption(Without spindle) | 1.2KW |
| Spindle Speed | 6000-24000rpm |
| Resolution | 0.005mm |
| Repeatability | 0.01mm |
| Voltage | AC220V,50Hz/60Hz(option:AC110V,50Hz/60HZ) |
| Drive motor | Stepper(option:Servo motor) |
| Working table | T-Slot with PVC board |
| Working Dictate | G Code*.u00*.mmg*.plt |
| Operating system | Nc-studio/DSP optional |
| Software environment | Windows98/2000/xp |
| Interface | USB |
| Flash memory | 128M(U Disk) |
| Software Compatability | Type3,,Ucancam,Artcam Software) |
| Running Environemt | Temperature: 0℃~45℃ |
| Relative humidity: 30%~75% | |
| Machine available |
Dust collector system, spindle cover, Japan Panasonic Servo motor, vacuum absorption table & vacuum pump system, Auto-oiling system, Tool-sensor, |
Applicable industry
Advertisement industry, handicraft industry, various types of man-made plate, LED, mold manufacturing, wood processing, craft manufacturing, light box cutting, building model, light equipment mold processing, sign and mark, acrylic board processing,PCB circult board, department cards.
Applicable material
Acryl ,wood, Aluminum, 3D technology, copper, PVC board, MDF board, PCB Board, breastplate, indoor & outdoor decoration, etc.
