Colorless Low Viscosity Brightness, Smooth Two Part Epoxy Resin With UV Resistance

Specifications:

                                    Resin                  Hardener

Appearance                        Colorless        Thick Liquid Colorless Liquid

Viscosity (25°C.mpa.s)             3000~5000                 40~100

Density (25°C.g/cm3)               1.05~1.15                1.00~1.10

Flash Point (°C)                      >140                     >140

3 Mixing Ratio (Weight) 3:1

4 Operation Time

Mixing volume100g, 45~60min on the temperature 25°C

5 Use of Technology

a) Clean the substrate.

b) According the blending ratio and well stirred.

c) After the drop glue to settle 10mins.

d) Flame deforming.

e) Curing.

6 Curing Condition

25°C 15~18Hours

70°C 1~1.5Hours

Description:

CW-D-202 is a solvent free crystal clear epoxy resin system, used for LED casting and coating, senior crafts transparent drape, electronic apparatus transparent, also can use as clear binder.

1. Good process performance, low viscosity, low smell, quickly curing, curing on normal temperature or heating cure.

3. Excellent UV resistance.

4. High hardness, with high anti-peel strength
