Quartz stone ultra mill, quartz powder ultrafine mill
USD $1 - $1
/ Set
1 Set(Min.Order)
- 100 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
- Gold mining jaw crusher equipment for sale, stone crusher machine
- First-rate high efficiency SZZ series self-centering vibrating screen with ISO 9001 Certificate
- China leader manufacturer ZHAOXIN high efficiency thickener
- Ore benefication thickener machine, dewatering thickener price
- china high quality center drive thickener, thickening equipment
- Shandong Province high efficiency center drive thickener NZ-12, thickening machine
Product Details
Brand Name: | CLIRIK | Place of Origin: | China | Model Number: | HGM |
Product Description
Detailed Product Description about Quartz stone ultra mill, quartz powder ultrafine mill, stone grinding mill
Quartz stone ultra mill, quartz powder ultrafine mill is mainly applied to grind non-inflammable, non-explosive and brittle materials with Mohs’ hardness under six. Such as calcite, chalk, limestone, dolomite, kaolin, gypsum, and talc etc, totally more than 100 kinds of materials. Product fineness can be controlled between 300~3000 mesh (47~5 micron)Comparable with ball mill, Quartz stone ultra mill, quartz powder ultrafine mill has features of low cost, high capacity, easy operation; Comparable with Raymond mill for coarse powder up to 325 meshes, it can produce fine powders between 47 and 5 microns (300 to 3000 meshes)
Production Line Configuration of Quartz stone ultra mill, quartz powder ultrafine mill, stone grinding mill
The whole set HGM Quartz stone ultra mill, quartz powder ultrafine mill consists of hammer crusher, bucket elevator, storage hopper, vibrating feeder, main unit, inverter classifier, cyclone collector, pulse deduster system, high pressure positive blower, air compressors and electrical control systemsWorking Principle of Quartz stone ultra mill, quartz powder ultrafine mill:
The main bearing and each dial are driven by electromotor of main machine through reducer, and numbers of rollers, which are rolling in the ring, are driven by dial through plunger. After crushed by hammer crusher, the big materials become small ones and are sent to storage hopper by elevator and further sent to the middle of first dial evenly by the electromagnetic vibrating feeder and feeding pipe. The materials will be driven to the edge of dial by centrifugal force and fall down into the ring, crushed and grinded by roller, and become powder after production of three rings. The high pressure centrifugal blower will inhale air from outside and blow the crushed materials to classifier. The rotating turbo in the powder concentrator will make the coarse powder return to the mill and reground, while the fineness will mix with the air and go into the cyclone and be discharged in the discharge bin, which is at the bottom of it. The air, which mixed with very little fineness, will be purified by impulse duster and discharged by blower and muffler.Should you have any questions, please do not hesitate to contact us:
Contact person: Cherry. Zhao
Tel: 0086-21-20236178
E-mail: clirik_grinder@163.com;clirik@grinding-mill.in
Address: No.19 Fuqing Road, Pudong New Area, Shanghai 201201, China.
