HB-3000 Brinell Hardness Tester
1. Functions
HB-3000 Brinell hardness tester is a testing equipment to test the Brinell hardness of ferrous metals, nonferrous metals and bearing alloys. It is also used for precision measurement of parallel plane surface and curved surface. The measurement is stable and reliable.
2. Features
1. Solid construction, good rigidity, high working efficiency, reliable and durable;
2. Mechanical reversing switch;
3. High-accuracy reading microscope measurement system;
4. Strong adaptability to working environment, widely used in the quality monitoring and control in production field;
5. Test accuracy can meet the standards of GB/T231.2 and ISO 6506-2.
3. Main Technical Parameters:
|
Model |
HB-3000 |
|
Range of measuring |
8-650HBW |
|
Test force |
1.839, 2.452, 7.355, 9.807, 29.42 KN(187.5, 250, 750, 1000, 3000kgf) |
|
Max. height of test specimen |
230mm |
|
Distance between Pressure head center and machine wall |
120mm |
|
Power supply |
AC 380V |
|
Dimension |
700 x 268 x 842mm |
|
Weight |
About 210kg |
4. Main accessories
|
Accessories |
Quantity |
|
Large test set |
1 |
|
Small test set |
1 |
|
V-shaped test set |
1 |
|
Steel ball indenter |
Φ2.5,Φ5,Φ10mm, each one |
|
Standard Brinell hardness blocks |
2 |
|
20-fold reading microscope |
1 |
