2013 Specialized Stumpjumper FSR Comp EVO Mountain Bike

SPECIFICATION :

FRAME
M5 hydroformed tubing, EVO geometry, tapered HT, PF30 BB, ISCG ’05, Command Post routing, 142mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 150mm travel
REAR SHOCK
Custom FOX Float CTD Evolution with AUTOSAG, Climb, Trail, Descend settings and rebound adj., 194x51mm
FORK
Custom RockShox Revelation RC3, 3P damper, tapered alloy steerer, 3-position compression and reb adj., 20mm Maxle Lite, 150mm travel
HEADSET
1-1/8 and 1-1/2" threadless, Campy style upper with 1-1/2" lower, cartridge bearings
STEM
Specialized XC Trail, 6061 alloy, 4-bolt, 6-degree rise, 31.8mm
HANDLEBARS
Specialized All-Mountain low-rise, 6061 butted alloy, 720mm wide, 8-degree backsweep, 6-degree upsweep, 31.8mm
GRIPS
Specialized Sip Grip, half-waffle aramid-infused, S/M: Regular, Others: XL thickness
FRONT BRAKE
Custom Avid Elixir 5 SL, hydraulic disc, alloy backed organic pads, HS-1 rotor. S/M: 180mm; L/XL 200mm rotor
REAR BRAKE
Custom Avid Elixir 5 SL, hydraulic disc, alloy backed organic pads, HS-1 rotor. S/M: 160mm; L/XL 180mm rotor
BRAKE LEVERS
Custom Avid Elixir 5 R SL, tool-less reach adj.
FRONT DERAILLEUR
SRAM X7, 10-speed, S3 direct mount for DMD, bottom pull
REAR DERAILLEUR
SRAM X9, 10-speed, mid cage Type 2
SHIFT LEVERS
SRAM X7, 10-speed, aluminum trigger, w/MatchMaker clamp
CASSETTE
SRAM PG-1030, 10-speed, 11-36
CHAIN
KMC X10, nickel plate, reusable Missing Link
CRANKSET
Custom SRAM S-1250, 7050 alloy arms, 10-speed AM double, PF30 spindle, S: 170mm, Others: 175mm
CHAINRINGS
36/24, w/ alloy guard
BOTTOM BRACKET
SRAM PF30, OS press-in bearing, sealed cartridge
PEDALS
Resin Test Ride Pedals with toe clips, CEN std.
RIMS
Roval 26, alloy disc, 28mm wide, 32h
FRONT HUB
Specialized Hi Lo disc, sealed cartridge bearing, 20mm thru-axle, 32h
REAR HUB
New Specialized disc, 4x-sealed cartridge bearing, 12mm thru-axle, 32h
SPOKES
DT Industry, 2.0 stainless
FRONT TIRE
Specialized Butcher Control, 2Bliss Ready, 60TPI, aramid bead, 26x2.3"
REAR TIRE
Specialized Purgatory Control, 2Bliss Ready, 60TPI, aramid bead, dual-compound, 26x2.3"
INNER TUBES
Ultralight presta
SADDLE
Body Geometry Henge Comp, hollow Cr-Mo rails, 143mm
SEATPOST
Specialized Command Post BlackLite, 3 position, adjustable height w/air spring, remote operated, single bolt head 30.9mm, S:100mm travel, Others: 125mm travel
SEAT BINDER
Command Post 34.9mm clamp, 7050 hard anodized alloy collar, single bolt
