155C Axial Wet High Temp Tantalum Capacitor
Negotiable
/ Piece
1 Piece(Min.Order)
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
CA82-175C Axial Wet Tantalum Capacitor
-
CA53-200C Gas Seal Wet High Temperature Tantalum Capacitor
-
CA306-180C Gas Seal Axial Wet Tantalum Capacitor
-
CA502-185C Axial Wet High temp Tantalum Capacitor
-
CA30 Series 125C Axial-lead Tantalum Electrolytic Capacitor
-
CA301 Series Non-solid Electrolytic Tantalum Capacitor
Product Details
| Place of Origin | China | |
| Model Number | CA82A |
Product Description
155C Axial Leads Tantalum Capacitor, High temperature Tantalum Capacitor,
155C Wet Tantalum Capacitor
Applications:
Silver case, gas seal, Cylindrical, Axial leads, High temperature sleeve, Polar
Good electric performance, High reliability, long life, Low DF and LC.
High temperature performance, Can use at 155 C
Suit for oil drilling deep well measurements and high temperature
Electronic devices DC or pulse circuit
Technical Characteristics:
Operation temperature: -55C~+155C
Capacitance Tolerance: +-10%;+-20%;-10%~+30%
Leakage Current:25C I<=0.002 CRUR(uA)or 2uA
155C I<=0.02 CRUR(uA)or 20uA
Capacitance Range: 2.2uf~1000uf
Voltage Range: 6.3V~125V
Rated Voltage: 6.3V, 10V, 16V, 25V, 40V, 50V, 63V, 75V, 100V, 125V
Capacitance with: 2.2uf, 3.3uf, 4.7uf, 6.8uf, 10uf, 15uf, 22uf, 33uf, 47uf, 68uf, 100uf, 150uf, 220uf, 330uf, 470uf, 680uf, 1000uf
