Home > Products > Power Film Capacitor > High Energy Density DC Link Filter Power Film Capacitor
High Energy Density DC Link Filter Power Film Capacitor
Negotiable
/ Piece
1 Piece(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
Product Description
Proven replacements for electrolytic capacitor banks, dry self healing metalized
Polypropylene Film capacitors, the product series is well suited for bulk DC storage, especially useful in DC link converter / inverter applications.
Long Life: > 100,000 Hours, Low ESL & ESR, High RMS Current Capability
Capacitance Range: 25uF ~ 2100uF
Capacitance Tolerance: Standard capacitance tolerance is 10%.
(Other tolerances available on request)
Operating Temperature Range: -40C TO +85C (+105C upon special request)
Hot Spot Temperature Calculation: H.S. = Tamb + (I2 x ESR) x Rth.
Failure Rate: 100FIT
Enclosure/ Construction: Aluminum housing with brass terminals, encased in a plastic cover
Voltage Rating: 600V ~ 3000V
¬600V/375uf, 600V/700uf
700V/660uf/1000uf/1250uf/1850uf
900V/250uf/450uf/620uf/750uf/1050uf/1140uf/1500uf/1600uf/2100uf
1100V/420uf/510uf/710uf/760uf/1020uf/1080uf/1420uf
1200V/175uf/300uf/340uf/420uf/600uf/640uf/840uf/900uf/1200uf
1400V/127uf/175uf/225uf
1600V/127uf/175uf/210uf/230uf/460uf/500uf/660uf
2000V/150uf/210uf/300uf/320uf/420uf/
3000V/25uf/35uf/45uf/65uf/95uf/130uf/145uf/190uf
