Water Proof LiFePO4 Lithium Battery Module12V110Ah With LED Indicator For UPS

Shenzhen O\\\'CELL Technology Co.,Ltd
Water Proof LiFePO4 Lithium Battery Module12V110Ah With LED Indicator For UPS thumbnail-1
Water Proof LiFePO4 Lithium Battery Module12V110Ah With LED Indicator For UPS photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
o\'cell
Place of Origin:
China
Model Number:
1
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name o\'cell
Place of Origin China
Model Number 1
Delivery Time:25DAYS
Certification:UL/UN38.3

Water proof LiFePO4 Lithium Battery Module12V110Ah With LED Indicator For UPS

Description:

O\'CELL integrates the slave module(PCBA) into batteries and developed a distinctive series of battery module. BMU will manage the whole system by opening/closing the contactor.

1. Interchangeable design to replace Lead Acid Battery.

2. The system can be scaled up by connecting modules in series and parallel.

3. IP56 dust and water proof design for the housing.

4. LED indicator will show the state of battery module.

Applications:

1. Eco battery power system for light electric vehicle, HEV, EV, etc.

2. Energy storage system for solar, wind or solar-wind system, etc.

3. Backup power system for telecom base station, communication equipments, power grid, banks, UPS, etc.

Specifications:

Item

IFM12-1100E1

Nominal Voltage

12.8V

Nominal Capacity(0.5C)

110Ah

Dimensions including terminals(L*W*H)

260*158*245

Approximate Weight

15Kg

Terminals, Female-threaded

M8*1.25

Specific Energy

90Wh/kg

Max. Constant Current

150A

Standard Discharge

Max. Pulse Current (30S)

300A

Cut-off Voltage

10V

Charge Voltage

14.6V

Standard Charge

Max. Constant Current

50A

Charge Time

2.5hrs

DC Internal Resistance (Approx.)

6mΩ

Water/Dust Resistance

IP56

Main Features

² Modules communicate via RS485 by BMU(Battery Management Unit)

² Inter-module & intra-module balancing via BMU

² Enhanced SOC calculation via BMU

² Charge and discharge control via BMU

² Temperature monitor via BMU

² Isolation measurement via BMU

² Easy installation up to 160KWh system in series & parallel

² Rugged mechanical and easy handling design

² Built in LED battery status indicator

² Can be charged with most lead-acid chargers

² Thousands of cycles under normal conditions

Competitive Advantage:

1. Intrinsic Safety from LiFePO4 Material

Lithium ion battery made with O\'CELL LiFePO4 cathode material can pass the safety tests easily such as nail test, 3C/15V over-charge test, etc.

2. Better Shelf Life

The shelf life of lithium ion battery can be measured by capacity retention at full charge state. Usually, the capacity loss of self-discharge can be divided into recoverable and irrecoverable capacity. O\'CELL LiFePO4 has excellent shelf life. The self-discharge rate is about 3% per month, the capacity can recover up to 98% after long time storage.

3. Good Rate Performance

The discharging voltage platform of O\'CELL LiFePO4 battery is flat. LiFePO4 power battery has good rate performance, the capacity @20C is more than 95% of 1C discharging capacity at room temperature. The maximum temperature rise is less than +20ºC.

4. Wider Operation Temperature

1.Operation temperature range:-20~+60℃;

2.Storage temperature range:-40~+60℃;

3.The capacity at -20℃ is more than 70%
