Integrative structure CO2 laser marking machine for leather, cloth, plastics,acrylic
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
100W / 150W high precision medicine CO2 laser marking machine for glass,leather, plastics
-
Automatic CO2 laser marking machine with high precision for rubber,plastics,glasses
-
High speed CO2 laser marking machine with stable performance for wood,bamboo
-
Industrial 1064nm water cooling laser marking machine, 50W, 75W, 100W for light-fixture
-
1064nm precision phone key laser marking machines for metallic oxides and ABS material
-
Precision 1064nm cutter laser marking machine for common metal and alloy
Product Details
Brand Name | XGY | Place of Origin | China | |
Model Number | XGY-CO2 10W XGY-CO2 30W XGY-CO2 55W XGY-CO2 100W XGY-CO2 150W |
Product Description
Certification:CE
Integrative structure CO2 laser marking machine for leather, cloth, plastics,acrylic
Leather marking machines use the CO2 laser and are general machine type. They adopt the rear focus mode and the optical system can be lifted and dropped freely and moved horizontally. They also adopt the high-performance CO2 laser, high-speed scanning vibrational mirror whose speed and precision are relatively high. The software uses Windows interface and and can be compatible with the documents exported by many kinds of software like Coreldraw, Autocad, Photoshop and etc. It supports the documents like PLT, PCX, DXF, BMP etc. and can use directly SHX and TTF character database, and it also supports the marking of the automatic coding, sequence, batch number, date, bar code and two-dimension code. The software has the graphic counter steering function. The computer can design the graphs and characters randomly, which is flexible and convenient and does not need print consumables, moreover, the processing cost is rather low. The laser marking is non-poisonous, pollution-free and resistant to wear and will not be transformed. The rotatable working platform can be selected which is applied to mark the cylindrical products. The suppliers of these accessories have the leading technology in the respective industry around the world. First-rate accessories, whose prices are moderate and can control the engraving depth randomly, ensure the high marking precision and speed, stable performance and long-term operation. It adopts the integrative design structure and new way of optical path seal, and it has the stable performance and nice shape.
Specifications:
Product Model: |
XGY-CO2 10W XGY-CO2 30W XGY-CO2 55W XGY-CO2 100W XGY-CO2 150W |
Laser Wavelength: |
1064nm |
Output Power: |
10W 30W 55W 100W 150W |
Power Stability: |
(8h)< ± 1% rms |
Quality of Laser Beam: |
M2<5 (@25A) |
Pulse Repetition Frequency: |
≤20KHz |
Focusing Lens: |
Standard (F160) |
Marking Range: |
70×70mm,100×100mm(standard), 150×150mm,200×200mm,300×300mm(optional) |
Marking Speed: |
250 characters per second (Times New Roman and the character height is 1mm) |
Smallest Marking Character: |
0.3mm |
Minimum Marking Line Width: |
50μm |
Electricity Needs: |
220V±22V / 50Hz / 30A |
Power Consumption of the Whole Equipment: |
<1.5KW |
Cooling Method: |
Cooling Method: air cooling |
Size of Host System: |
1290 mm×410 mm×1200mm |
Size of Controlling System: |
630 mm×630 mm×820mm |
Size of Cooling System: |
560 mm×430 mm×770mm |
Weight of Host System: |
40kg |
Weight of Controlling System: |
50kg |
Weight of Cooling System: |
30kg |
Applications:
Applicable material: Non-metal materials such as cloth, tiles, paperboard, papers, leather, PU leather, trademark embroidering, plastics, bamboo & wooden products, woods, organic glass, acrylic, jade, shell, ox horn, animal sebum, double-color sheet, ABS board, PVC board, fiber and composite materials.
Applicable industry: It can be widely used in the glasses, button, plastics, sign, packaging, leather, cloth, ceramics, glass, crystal, rubber, electric appliance, craft ware, wood and bamboo ware industries.
