5.7” Color Date, batch Thermal Transfer Overprinter Print Area 32 mm x 30 mm (1.3” x 1.2”)
＊ Consistent, high quality print
VJ6210 delivers 300 dpi images on a wide variety of flexible packaging materials. This efficient printer is well-suited for applications in snack food, bakery, confectionery, frozen and refrigerated foods, bagged fresh vegetables and dried fruits markets.
＊ Real-time variable data
The internal clock function in the VJ 6210 provides on line printing of variable and real-time data such as best by date, time, batch and lot codes, shift code and production line ID.
＊ Long production runs
The VJ 6210 features a proven, clutchless ribbon drive that is highly reliable. Ribbon tension is consistently maintained, virtually eliminating
ribbon-related downtime. A 600 meter ribbon length capacity requires less frequent ribbon changes than hot stamp or other competitive TTO equipment.
＊ Simple to operate
The intuitive, graphical user interface incorporate easy to learn, icon-based controls and a WYSIWYG image display to reduce set up errors. Two to three keystrokes, and you’re ready to print!
＊ Low cost of ownership
The VJ 6210 is designed to operate efficiently. The bi-directional ribbon drive allows unused ribbon to be recaptured after each print, providing more prints per roll and a low cost of ownership.
Specifications
Printhead
·32 mm, 300 dpi (12 dots / mm)
Print Area
·32 mm x 30 mm (1.3” x 1.2”)
Printing Modes
·Continuous & Intermittent modes in the same machine
Print Speed
·Intermittent: 50 mm/sec. to 200 mm/sec. (2.0”/sec to 7.9”/sec)
·Continuous: 40 mm/sec. to 500 mm/sec. (1.6’/sec to 19.7”/sec)
Operator Interface
·5.7” Color QVGA CSTN (240 x 320 pixels) LCD and touch screen
·WYSIWYG print preview
·On-board diagnostics
·3 levels of password protection
·Multiple language support
Ribbon Drive
·Solid-state, clutchless bi-directional ribbon drive, including
·Ribbon break detection
·End of reel detection
·Ribbon consumption indication
·Ribbon Save mode: Interleave(50% saving of ribbon)
Printing Capabilities
·Full downloadable font support using Windows True Type fonts
·Fixed and variable text and numeric data
·User entered text and numeric data (including Chinese)
·Flexible date /time formats (based on internal real time clock)
·Auto best before date calculations
·Flexible Shift code formats
Ribbon Length
·600 meters (656 yds.) available in variety of grades and colors
Ribbon Widths
·22 mm and 33 mm (0.9” and 1.3”)
Image Design Management
·Created using CLARiSOFT
·Stored locally in printer’s internal memory (128MB capacity)
·Loaded via USB memory stick or RS232
Remote Coder Configuration Software
·Clarity Configuration Manager (included)
External Communications
·USB memory stick, RS232 (binary communications only)
External Inputs
·Print Go
·Inhibit Print
·Quadrature encoder (single phase not supported)
External Outputs
·Fault
·Warning
·Busy
·Printing
Air Supply
·4-6 Bar, locally regulated
Power Supply
·90-240 VAC 50/60HZ
Operating Temperature
·5-40℃(41-104℉)
