Small Size Portable Brown Gas Generator / Hho Gas Generator
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Place of Origin:
China
Model Number:
OH100 OH200 OH300 OH400
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
Place of Origin
China
Model Number
OH100 OH200 OH300 OH400
Small Size Portable Brown Gas Generators Introduce
1 Small Size Portable Brown Gas Generators
1.1 Oh100 Brown Gas Generator
Model Number: OH100
AC Voltage Requirement (V) :220/110
Phase: single
Power Consumption (kW/h): 0.4
Max Gas Output: 100L/h
Max. Working Pressure (kg/cm2): 1.3
Max. Water Consumption (L/h): 0.06
Water Feed: manual
Max. Flame Modifier Consumption (L/h):0.05
Flame Modifier Feed: manual
Dimensions - LxWxH (mm): 480*280*360
Gross Weight (kg): 12
Ventilation Space Requirement (mm): 200 in each direction
1.2 OH200 Brown Gas Generator
Model Number: OH200
AC Voltage Requirement (V) :220/110
Phase: single
Power Consumption (kW/h): 0.8
Max Gas Output: 200L/h
Max. Working Pressure (kg/cm2): 1.3
Max. Water Consumption (L/h): 0.11
Water Feed: manual
Max. Flame Modifier Consumption (L/h):0.1
Flame Modifier Feed: manual
Dimensions - LxWxH (mm): 620*280*360
Gross Weight (kg): 33
Ventilation Space Requirement (mm): 200 in each direction
1.3. Model Number: OH300
AC Voltage Requirement (V) :220/110
Phase: single
Power Consumption (kW/h): 1.2
Max Gas Output: 300L/h
Max. Working Pressure (kg/cm2): 1.3
Max. Water Consumption (L/h): 0.17
Water Feed: manual
Max. Flame Modifier Consumption (L/h):0.15
Flame Modifier Feed: manual
Dimensions - LxWxH (mm): 780*380*520
Gross Weight (kg): 38
Ventilation Space Requirement (mm): 200 in each direction
1.4 OH400 Brown Gas Generator Model Number: OH400
AC Voltage Requirement (V) :220/110
Phase: single
Power Consumption (kW/h): 1.4
Max Gas Output: 400L/h
Max. Working Pressure (kg/cm2): 1.3
Max. Water Consumption (L/h): 0.23
Water Feed: manual
Max. Flame Modifier Consumption (L/h):0.17
Flame Modifier Feed: manual
Dimensions - LxWxH (mm): 950*380*520
Gross Weight (kg): 45
Ventilation Space Requirement (mm): 200 in each direction
2. About Okay Energy Equipment Co., Ltd.
High-tech Development Zone, Changsha, Okay Energy Equipment Co., Ltd specializes in research, manufacturing, sales Brown Gas generator, water welding Machine, flame polishing machine and other products. We maintain close cooperation with institutions of higher learning institute, continue to improve old products and develop new products, do our best to meet the market demand.
At present, we can provide two serials type products: small portable Type and medium type Brown Gas generators. The small portable type is OH100, OH200, OH300, OH400 and the medium type Brown Gas is OH1000, OH1500, OH3000, and OH5500 OH7500.
All our products are in accordance with international quality management system manufacturing. Rigorous testing before delivery.
We have five national invention patents, three utility model patents, Our technology development team led by Dr, the existing 20 technical personnel, production staff have 50 people. We can produce 200 units per month hydrogen generator to meet the needs of customers. Integrity is our promise, quality is our goal. We are open arms to welcome foreign friends to visit our company and purchase our products. Together to create \"Energy Saving, Emission Reduction” new world.
3. About OKAY ENERGY Technology
Okay Energy Co., Ltd specializes in research, manufacturing Brown Gas generator, owned many patents.
1) Patented Integration of Water Electrolysis Cell Forming
Our electrolysis cell Integration by used Large Module, in order to make sure No Leakage,Explosion-proof ,Long Life Cycle.
2) Patented Electrolysis Power Supply based SCM
Our Power Supply is special designed for Electrolysis.
Example:
2.1 Constant current control by temperature feedback control
2.2 Current adjust by user to meet the constant flux of Brown Gas gas
2.3 Efficient energy conversion(AC TO DC) based IGBT
2.4 Special cooling design for working 24 hours continues.
3) Patented Multi-layer ANTI-FIRE Water Seal Technology
Water Seal Device is important unit of Brown Gas generator. this unit is designed for backfire-proof, It work 100% ok.
4) Automatic Water Level Detection Technology
We design by myself ,it used for detect the water level of the electrolysis cell and water -deposit tank . When water is too Lower, the alert lamp is light . when water is lowest, the power supply is switch off to proof the Brown Gas generator.
5) Water Automatic Replenishment Technology
when water of the electrolysis cell is too lower, the system will auto pump water from water -deposit tank .
6) High-efficiency Gas Water Separator Technology
This Technology is used to separate the water from gas, ensure the gas is pure. if the Brown Gas gas have some water even little , the temperature of the Brown Gas flame will become lower.
7) Electrolyte -Automatic Cycle Technology
We used static way to realize Electrolyte Cycle, don\'t used pump. Because the pump is a mechanic unit that is easily damaged.
4. Okay Energy Application of Brown Gas Geberator 4.1. Jewelry Industry:
For welding kinds of chain and string made of platinum, gold, silver, copper, stainless steel, etc.
For mending tiny sand holes on jewelry casting.
For jewelry repairing (reforming, casting, welding).
4.2 Electronic Industry: For welding enameled wire, welding LED wafer, flame-treating circuit board
4.3Medical Industry: For welding metal fittings and mending sand holes in dentistry. No-carbon flame disinfection or glass seal.
4.4Laboratory: Providing convenient, safe and clean oxyhydrogen flame.
4.5 Organic Glass Industry: Quick and fine polishing for acryl (organic glass), solving problems that grinding wheel cannot achieve.
4.6 Others: For welding or heat treating small metal parts. Iron Cutting, Catalytic combustion of other fuels
5. Related Document Researched By Okay Energy
5.1. what is Brown Gas generator
Brown Gas generator is able to separate clean soft water (H2O) into hydrogen and oxygen gases, using a small amount of electric power through a special process. These gases are then mixed and delivered for use in a wide variety of applications, such as heating, brazing, cutting, etc. which currently use LPG or other gas for fuel. When burned, this fuel generates no green house gases or pollutants, and burns at virtually 100% efficiency. This certainly has the potential for becoming the most significant advancement in fuel for the 21st century.
5.2. Why I used Brown Gas generator
5.2.1 Maximum Safety
@ Steady, reliable fuel delivery. Fuel is available immediately after machine is switched on. No volatile fuel tanks which can rupture or explode.
@ Multiple safety devices, including overheating and in-sufficient water cut-off switches, will automatically turn off power to ensure the safety of both equipment and user.
5.2.2 Environmentally Friendly
@ The Fuel generated by our machines burns completely without creating pollutants, toxic fumes, or public nuisance.
@ Does not generate hydrocarbons, carbon monoxide, or carbon dioxide. 5.2.3 High Mobility
@ Our generators come equipped with wheels to facilitate moving the generators to the job, not the other way around.
@ Our generator immediately generates fuel as needed, eliminating the need for dangerous awkward gas tanks.
@ Fuel can be used for long periods of time without overheating peripheral equipment
5.2.4 High Temperature & Calorific value
@ Calorific value is 34000Kcal/kg
@ The flame Temperature is over 2800 oC , It could melt Refractory metals and none-metals 5.2.5 Low Cost & Maximum Economy
@ Fuel is generated using only electricity and clean soft water.
@ Both economical and practical when compared to the currently used LPG, Propane, or acetylene.
5.2.6 Low Heat Dispersal
@ Use of this fuel provide a more focused heat source with less heat loss, maintaining a more comfortable, safer, lower fatigue working environment.
