7.5-15KW Aluminium and GCr15 Advanced Steel PU Sandwich Panel Forming Machine
Components of the machine:
Un-coiler
Leveling device
Main forming machine
Foaming machine
Adjusting device
Punching device
Pneumatic following cutting device
PLC Control system
Finished product shelf
Main specification and price:
1. Suitable material:Aluminium
2. Working speed: 15 m/min
3. Steps:40
4. Material of roller:GCr15 advanced steel, precision-machined, high frequency quenching HRC58-62
5. Material of main roller:#45 advanced steel (Diameter: ￠40)
6. Driven:Gear, Gimbals
7. Main power: 7.5-15KW
8. Cutting:Pneumatic following cutting
9. Material of cutting knife: Cr12Mov, Quench HRC58-62
10. Cutting power:2.2KW
12. Dimension of the whole line: 37000mm*700mm*900mm
13. Weight: Approx. 12 Ton
15. Forming thickness:0.6-1.2mm
Layout:
