Guangdong JD Environmental Protection Technology Co., Ltd: Shangluo, Shaanxi, China; Main products: Cob LED Light

Home > Products > Cob LED Down Light > High Luminous AC100V - 240V 30W Recessed Cob LED Down Light For Staircase, Office

High Luminous AC100V - 240V 30W Recessed Cob LED Down Light For Staircase, Office

FOB Price

Negotiable

1 (Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	JD		Place of Origin	China
Model Number	JD-1609-30-2

Product Description

Delivery Time:3-5working days after received deposit.
Certification:CCC, CE, RoHS

High Luminous AC100V - 240V 30W Recessed Cob LED Down Light For Staircase, Office

30W RECESSED COB LED DOWN LIGHT 8 INCHES

1. Integrated low power multi-chip COB surface light-source, with independent IP protection, high quality Epistar chip, each chip is 0.08W, with low current load (26mA) and efficient circuit design

2. Low heat production, perfect heat dissapation, within 70° for junction temperature, the luminous decline is no more than 5% within10, 000 hours, ensuring a long life span

3. High Luminous efficiency (> 80LM/W for light engine), radiation angle is 120º, no need of secondary optical design

4. Japanese IC power supply, specially designed based on our light board, no electrolytic capacitor, well matched the long life design of our LED, with high power factor (>90%) and transfering efficiency (>85)

5. No glare, no double image, no color shifting

6. Simple structual and installation: PC lighting fixture without extra cooling structure, buit-in driver, light, convenient and cost saving for transportation and installation

7.Diverse options: 3000K, 4000K, 5000K for warm white, true white and cold white color temperature, clear or frosted lens for choice

8. CCC, CE, RoHS certificates, 3 years\' gurantee from the date of delivery (1 to 1 free repacement for any quality defective)

Applications:

Hotel, Restaurant, Office, Shopping Mall, Super Market, Residence, Hospital, Coffee Bar, Club, Staircase, Entrance, Toilet

Specification:

	Model:	JD-1609-30
Input Voltage:	AC100V-240V, 50/60Hz
Power:	30W
Lumens:	1000-1200LM (LED Engine)
Beam Angle:	120°
Installation Hole:	φ210mm
Index:	RA70
Fixture Material:	PC, Aluminum
Lens:	Clear or Frosted PC
Temperature Color:	3000K, 4000K, 5000K
Certificate:	CCC, CE, RoHS
IP:	40
Life Span	50000 Hours
30W Recessed Down Light	Dimension:	Φ108mm*H74mm
	Key Components:	Unique Light Board with IP protection, Japanese IC Power

Dimension (mm):

Detailed Images:

Competitive Advantage:

1. Novel design: COB LED down light , Unique circuit design, using high-performance constant-current drive , thereby achieving a highly efficient energy-saving purposes. The surface shell with special aluminum alloy, have good heat dissipation, beautiful appearance , installation and replacement, safe and convenient usage.

2. Efficient and energy-saving: With high-performance constant-current power supply, conversion efficiency is greater than 90%, 60% energy saving, life span is up to 30000-50000 hours.

3. Stable Performance: Apply to AC85-265V 47-63Hz wide voltage, broad frequency input, AC conversed to DC, reducing LED decay, starting fast, no flicker, hard to damage product under frequent turning on and off.

4.Environment friendly: Using new LED light source, no mercury, lead and other hazardous substance, no pollution to environment. It will not produce ultraviolet and infrared and other rays, causing very low heat, no attraction to mosquitoes, very clean and healthy for indoor usage. The product is re
