Signal Level Meter (5-870MHz)

Name: Signal Level Meter (5-870MHz)
Brand: YOUXIN
SKU: 147573784
Availability: InStock

Ningbo Youxin Optic-Electronic Technology Interprise

Negotiable MOQ: 1 Case (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

YOUXIN

Place of Origin:

China

Model Number:

SLM-1220

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Brand Name YOUXIN

Place of Origin China

Model Number SLM-1220

Signal level meter, 5-870MHz, level range 30~115dBuV, LCD display, 2 channels test at same time, max 125 channels scan, 75 ohm BNC or F connector.

Feature: Download DOC: $\"SLM-1220\"$ SLM-1220

◇ Channel and spectrum testing

◇ Scan mode, spectrum mode and TILT mode

◇ Testing level, voltage, C/N etc

◇ Large LCD screen display

Parameter

Item	Specification
Frequency and Level
Frequency range	46 — 870MHz
Resolution bandwidth	280KHz ± 50KHz
Channels	All user Channels
Level range	30dBμV — 115dBμV
Accuracy	±1.5dBuV(under room temperature) ±2.5dBuV(- l0 — +50℃)
Input impedance	75Ω(BNC or F connector)
Wave detection	Peak value
Auto scan testing(it has no such function under this version)
Max channel Scan	125 Channels
Scan range	All Channels within 46--870MHz
Scan speed	30 Channels/Min
Memory groups	14 Groups(00--13) Each group store Max 100 Channels
Voltage
Voltage range	0 -- 100VAC
Accuracy	±1.5V
Resolution	0.1V
C/N (only for reference)
Level range	80dBuV – 105dBuV
Others
Dimension	215mm x 95mm X 47mm
Weight	550g (without charger)
Working temperature:	-10℃ ~ + 40℃
Display LCD	STN LCD with back light
Power
DC supply	DC 7.2V/1.6Ah rechargeable battery
AC supply	AC 220V/50Hz±10%
Battery working hours	longer than 4.5 hours at continuous working mode
Recharging hours	12 -- 14 hours
