Digital Signal Level Meter T95

Features: Download DOC:DIGITAL SIGNAL LEVEL METER T95

1. View all free to air DVB-T channels directly on the TV screen.

2. New high resolution 3.5 inch LCD display

3. Professional spectrum screen with fast reaction times.Bandwidth -able,with channel test function

4. For terrestrial digital and analogue installation

5. Accurately analyse and measure C/N,MER and BER

6. Fast auto scan function screen.

7. Scans the full plan ed

8. Multi channel plan ion from memory. Edit by hand or PC.

9. With COFDM demodulation

Specifications:

A: COFDM Demodulated

Frequency range: from 46MHz~870MHz

Level range: 35dBμV-110dBμV

Level measurement accuracy: 2dB

Measurement resolution: 0.1dB

MER: 19~32dB

BER: 1.0E-2 to 1.0E-8

C/N:shown and linked to Pass,Margin,Fail

Indicator:Signal Level

Punctured codes: 1/2,2/3,3/4,5/6,7/8

Demodulation: QPSK,16QAM,64QAM

B: Analogue television channels Measurement

Frequency range: 46MHz~870MHz

Level range: 25dBμV-120dBμV

Input impedance: 75Ω

Level measurement accuracy: 1dB

Measurement resolution: 0.1dB

Interchangeable input connector: F

Power supply at RFIN: 5V(100mA)

Working time: 3-4 hours

Connecter: RS232

Work temperature: 0℃-40℃

Computer: Windows 2000/windows XP
