GSM / CDMA / PCS / 3G / WLAN System High Gain Multiband Dual Polarization Panel Antenna
Feature:
● High Gain
● Full day for working
● Optimized dimension
● Dual polarization
Application:
● GSM/CDMA/PCS/3G/WLAN System
● Wireless telecommunication &Data transmission system
Specification
|
RSDP-800-2500-14 |
|||
|
Electric Specifications |
|||
|
Frequency rang |
806～960 |
1710～2200 |
2200～2500 |
|
Polarization |
±45° |
||
|
Gain(DBi) |
2×10 |
2×12 |
2×12 |
|
Beamwidth(0°) |
H:65 V:60 |
H:65 V:38 |
H:65 V:30 |
|
F/B ratio(DB) |
≥25 |
≥25 |
|
|
Input Impedance(Ω) |
50 |
||
|
VSWR |
≤1.5 |
≤1.5 |
|
|
Max power(W) |
400 |
200 |
|
|
Mechanical Specifications |
|||
|
Connector model |
2×N Female |
||
|
antenna size (mm) |
1200*280*80 |
||
|
Packing size(mm) |
1235*315*150 |
||
|
Antenna weight (kg) |
7 |
||
|
Radome material |
UPVC |
||
|
Radome color |
Gray |
||
|
Mechanical tilt(°) |
0～10 |
||
|
Working Temperatu(°c) |
-40～60 |
||
|
Rated Wind Velocit(m/s) |
60 |
||
|
Pole diamete(mm) |
50～75 |
